China anodized color coated aluminum coil pe pvdf prepainted
Product |
pe pvdf prepainted aluminum coil |
Thickness |
0.01mm-10mm |
Width |
800mm-1900mm |
inner diameter |
505mm (as per requirements) |
weight |
2000kg-3000kg |
Material |
1050,1060,1100,3003,3004,3105,5052,5005, 5754,5083,6061,6063 etc |
Temper |
O,H12,H14,H16,H18,H24,H26, H32,H34,H111,H112,T3,T5,T6 etc |
Surface |
flat |
Packing |
Export standard wooden pallets (as per requirements) |
Payment Terms |
30% T/T in advance as deposit,70% balance against the B/L copy or 100% irrevocable L/C at sight |
Minimum Order Quanlity |
5 tons pre size |
Delivery time |
20-30 days after receiving L/C or deposit |
Loading Port |
Tianjin China (any port in China ) |
Remark |
Specific requirement of alloy grade,temper or specification can be discussed at your request |
Packaging Details:
Thickness>0.18mm paper sleeve thickness:505mm
Thickness<0.18mm Aluminium sleeve thickness:150mm
1). Each coil to be securely tied with two bands.
2). the contact points of these bands on the coil edge to be protect with edge protectors.
3). Coil then to be properly wrapped with plastic film ,woven belt, resistant paper.
4). Wooden or iron pallet can be used or as your requirements.
Performance of the coating
|
Aluminum Thickness |
Coating Thickness |
MEK |
T- Bend |
Impact |
Adhesion |
Pencil Hardness |
Boiling Water Proof |
0.3-1.5mm |
≥18μm |
≥100 Times |
≤2T |
50 kg•cm |
0 Grade |
≥HB |
no change within 2 hours |
0.2-0.28mm |
≥18μm |
≥100 Times |
≤2T |
30kg•cm |
0 Grade |
≥HB |
no change within 2 hours |
0.15-0.18mm |
≥18μm |
≥100 Times |
≤3T |
20 kg•cm |
0 Grade |
≥HB |
no change within 2 hours |
0.08-0.12mm |
≥16μm |
≥80 Times |
≤4T |
10 kg•cm |
≤1 Grade |
≥HB |
no change within 1 hour |
0.022-0.06mm |
≥12μm |
≥50 Times |
- |
- |
≤1Grade |
≥HB |
no change within1 hour |
Construction and decoration ( aluminum- plastic laminated panel,aluminum honeycomb panel, antiflaming
cladding, ceilings, Persian blinds, roller shutter doors, garage doors), electronic appliances (computer casing, appliances panels), lighting decoration, furniture, solar reflections, air-conditioner air pipes, rain-shelters and drainage cullis etc.
Henan FASTARRIVER Trade Co., Ltd., located in Zhengzhou City (center China), is a professional supplier of aluminum products. The main products are 1 Series, 3 Series, 4 Series, 5 Series, 6 Series, 7 series, 8 series, and dozens of alloy grades. There are aluminum sheet, aluminum coil, aluminum foil, PS version of the base, electrolytic capacitor with aluminum foil, Single zero foil, double zero foil material, brazing sheet, embossing roller and coating materials, gold and silver mirror aluminum, aluminum circle, and so on.
Our products are exported to North America, South America, and the European markets. To meet various requirements from customers, we have established a complete quality control system from incoming material inspection, production process control, to final inspection according to the ISO9001 system.
Q: How to contact your company?
A: With TradeManager or Skype or Email or the other ways we have written upon.
Q: Can you give us a quotation right now?
A: Please give us detailed technical data. Then we will make a design and quotation for you as soon as
possible.
Q: What is the MOQ (Minimum Order Quantity)?
A: 1 ton
Q: Do you provide your products catalogue?
A: Of course, I will send it to your E-mail if it's convenient to you.
Q: What are your payment terms?
A: We accept L/C, D/A, D/P, T/T, Western Union, MoneyGram etc.
Q: Do you supply other products?
A: Yes, our main products include Aluminum Sheet, Aluminum Coil, Color Aluminum, Mirror Aluminum,
Embossed Aluminum, and Aluminum Foil, Aluminum Circle, Aluminum Tube etc.
At the same time, different dimension can be customized .Welcome your inquiry.
