Specifications
1.18 Single Phase Circuits (or 6 three phase circuits)2.TOU, 4 Tarrifs, 14 Schedules,14 Segments
3.Data Logging, Energy Meter
DESCRIPTION
AcuRev 2000 series is the next generation multifunction energy meter developed and manufactured by Accuenergy. It performs real-time metering, measures energy consumption and monitors power quality for up to 18 single phase circuits (or 6 three phase circuits) in one unit. AcuRev 2000 series meter is ideal for multi-tenants submetering applications such as in commercial facilities, residential apartments and industrial environment. In addition, communication ports such as infrared, RS485 serial communication and Ethernet, IO ports that support pulse counting from water and gas meters and kWh pulse output are available. Due to its communication capability, compact size and ease of use nature, this product can be easily integrated into new and existing energy management systems.
APPLICATIONS
• Commercial Complex and Malls • Schools, Colleges and Universities
• Public Services and Establishments • Hotels and Office Buildings
• Intelligent Distribution Systems • Condominium and Service Appartments
• Energy Management Systems • Utilities and Industrials
• Power and Load Monitoring Systems • Railway and Subway Systems
FEATURES
• Comply to IEC 62053-21 Measurement Standard
• Support up to 18 Individual Channels for Energy Measurement
• Multifunction Power Metering, Monitoring and System Analysis
• Data Logging and Load Status Recording
• Multiple Communication Ports
• Module Design
• Extented Power Supply (100 - 415 Vac)
• Data (Pulse) Collection from Water and Gas Meter
Time of Use (TOU)
TOU can be used according to different regional billing requirements. AcuRev 2000 series supports up to 4 tarrifs, 14 schedules, 14 segments, weekend and holiday programming as well as energy (kWh) pulse output.
Data Logging
With 4MB of onboard memory, AcuRev 2000 series can log real-time metering parameters, I/O status, and energy measurement. These information can be used for historical trending and system analysis.
Display and Installation
AcuRev 2000 series has a scrolling display LCD screen for multi-circuits parameter readout. The display module can be installed together with the base unit or can be mounted on a panel independently. For cost saving and easy installation, up to 20(80) Amp current (per phase) can be directly connected to the meter. External current transformers (CT) can be used for retrofit applications or high current systems as well.
Power Quality Analysis
Power quality parameters such as voltage and current THD, individual voltage and current harmonics, voltage crest factor, current K factor, voltage and current unbalance etc will be monitored.
I/O Option
I/O ports from the AcuRev 2000 series expands the capability and functionality of the energy meter. Standard output ports provide energy (kWh) pulse output and time pulse output; digital inputs (DI) provide pulse counting from water, electricity and gas meter, and monitor switch status; relay outputs (RO) react upon alarming conditions.
Communication
Supports multiple communication ports including:
• Modbus-RTU via RS485 serial port
• Infrared data port
• Modbus-TCP, SMTP and HTTP via Ethernet
• DNP 3.0
FUNCTION
