Help CenterSmall Wave Soldering Machine LF250 Series/lead-free-capable Wave Soldering Machines Feature Compact
Related Products
-
Small Wave Soldering Machine LF250/Compact Dual Wave for PCBsNegotiableMOQ: 1 Set -
Lead Free Wave Solder Machine LF230A/Benchtop Wave Solder Machine/Economical Wave SolderNegotiableMOQ: 1 Set
-
Lead Free Wave Soldering Machine LF233/Small Wave Solder Machine/Double Wave SolderNegotiableMOQ: 1 Set
-
Dual Wave Soldering in an Ultra-compact Footprint LF250/Double Wave Soldering MachineNegotiableMOQ: 1 Set
-
Wave Soldering Machine LF260 Series/Lead Free Wave Solder Machine/Automatic Wave SolderingNegotiableMOQ: 1 Set
Lead free wave soldering machine LF250 with perfect performance, complete with flux spray system, preheating, wave solder and cool modules.
Features
•Compact design; only 2100 mm long;
•Corrosion resistant solder pot, lead-free and lead solders, PID temperature control;
•Dual-wave system with Taiwan variable-frequency controlled motors and independent adjustment of wave crest height up to 8mm;
•Energy-saving mode with automatic board detection and timer to turn off pump motors during periods of inactivity;
Specification
solder type | Lead free |
max PCB | 50—200mm |
Components height | Above ≤130mm under ≤8mm |
Capacity | 100KG |
Preheating length | 600mm |
Temperature accuracy | ±2 |
spray way | Foam/spray |
temperature range | room - 300 |
wave height | 0—8mm, keep balance wave crest |
heating controlling | PID |
speed | 0—1800mm/min |
start/normal power | 12KW/6KW |
Power supply | 380V 3 phase 50HZ |
Preheating temperature | room—260°C |
Width adjust | Manual adjusting |
Transmit angle | 3-8 |
Direction | right→left (left→right optional ) |
controlling accuracy | Taiwan motor |
Weight (Kg) | 250KG |
Dimension | 1400*1000*1500MM it is 2100mm when the machine include loading and cooling system. |
