Lead free wave soldering machine LF250 with perfect performance, complete with flux spray system, preheating, wave solder and cool modules.
Features
•Compact design; only 2100 mm long;
•Corrosion resistant solder pot, lead-free and lead solders, PID temperature control;
•Dual-wave system with Taiwan variable-frequency controlled motors and independent adjustment of wave crest height up to 8mm;
•Energy-saving mode with automatic board detection and timer to turn off pump motors during periods of inactivity;
Specification
solder type |
Lead free |
max PCB |
50—200mm |
Components height |
Above ≤130mm under ≤8mm |
Capacity |
100KG |
Preheating length |
600mm |
Temperature accuracy |
±2 |
spray way |
Foam/spray |
temperature range |
room - 300 |
wave height |
0—8mm, keep balance wave crest |
heating controlling |
PID |
speed |
0—1800mm/min |
start/normal power |
12KW/6KW |
Power supply |
380V 3 phase 50HZ |
Preheating temperature |
room—260°C |
Width adjust |
Manual adjusting |
Transmit angle |
3-8 |
Direction |
right→left (left→right optional ) |
controlling accuracy |
Taiwan motor |
Weight (Kg) |
250KG |
Dimension |
1400*1000*1500MM it is 2100mm when the machine include loading and cooling system. |
