Small wave soldering machine LF250 Series/Spray 100Kg

Name: Small wave soldering machine LF250 Series/Spray 100Kg
Brand: GLICHN
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

Lead free wave soldering machine LF250 with perfect performance, complete with flux spray system, preheating, wave solder and cool modules.

Features

•Compact design; only 2100 mm long;

•Corrosion resistant solder pot, lead-free and lead solders, PID temperature control;

•Dual-wave system with Taiwan variable-frequency controlled motors and independent adjustment of wave crest height up to 8mm;

•Energy-saving mode with automatic board detection and timer to turn off pump motors during periods of inactivity;

Specification

solder type	Lead free
max PCB	50—200mm
Components height	Above ≤130mm under ≤8mm
Capacity	100KG
Preheating length	600mm
Temperature accuracy	±2
spray way	Foam/spray
temperature range	room - 300
wave height	0—8mm, keep balance wave crest
heating controlling	PID
speed	0—1800mm/min
start/normal power	12KW/6KW
Power supply	380V 3 phase 50HZ
Preheating temperature	room—260°C
Width adjust	Manual adjusting
Transmit angle	3-8
Direction	right→left (left→right optional )
controlling accuracy	Taiwan motor
Weight (Kg)	250KG
Dimension	140010001500MM it is 2100mm when the machine include loading and cooling system.

Beijing Glichn S&T Development Co., Ltd.: Contact namekaren peng; Phone86-01-58494188; Addressbeijing Chaoyang,Liaoning
