Semi Automatic Solder Paste Stencil Printer LED500/ LED Production And Assembly Reflow Ovens
US$ 100 - 1,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Beijing, China
Brand Name:
GLICHN
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Semi Automatic Solder Paste Stencil Printer LED500/ LED Production And Assembly Pick And Place MachineUS$ 700 - 1,100MOQ: 1 Set -
High Precision Screen Printer/PCB Solder Paste Screen Printer Machine SP40 Contrapuntal CalibrationNegotiableMOQ: 1 Set
-
Semi Automatic Solder Paste Stencil Printer LED500/LED Solder Paste MixerUS$ 500 - 5,000MOQ: 1 Set
-
Semi Automatic Solder Paste Stencil Printer LED500/ LED Production And Assembly Single and Double Direction PrintingUS$ 100 - 1,999MOQ: 1 Set
-
Semi Automatic Solder Paste Stencil Printer LED500/LED Pick and Place Wave SolderUS$ 100 - 200MOQ: 1 Set
Condition
New
Place of Origin
Beijing, China
Brand Name
GLICHN
Model Number
led 500
Voltage
220V 50/60Hz
Power(W)
200
Weight
250Kg
Dimension(L*W*H)
900*900*1650mm
Certification
CE
Warranty
one year
Semi Automatic Stencil Printer LED500
Features:
A . Servo system to precise alignment;
Features:
A . Servo system to precise alignment;
B . Precision slideway and ZD motor (Tai Wan) drive scraper station to get good printing accuracy;
C . Scrapers can be rotated up 45°and fix them, it is convenient to clean and replace;
D . Scraper station can be adjusted from front to back, it can help confirm the best printing position;
E. Groove and Pin are on the working table, single and double sides can be printed; Install and adjust are easy and convenient;
F . Correct accuracy is moving stencil and X,Y,Z adjustment;
G. VIGOR PLC (Tai Wan) and touch screen operation system;
H . Single and double direction printing;
I . Automatic counter function for production analysis;
J . Scraper angle is adjustable;
K . Screen protection function on touch screen; time and speed can be adjusted at any time;
L . Alarm function when touching stencil; Cleaning stencil on time to get good printing;
M . EW program design in the machine;
Specifications:
Working table size |
350X1300mm |
Stencil size |
400X1500mm |
PCB size |
320X1200mm |
PCB thickness |
0.2--2mm |
Printing position fix |
PCB Outer Or Pin Positioning |
Working table adjustment |
Front/back ±10mm R/L ±10mm |
Printing accuracy |
±0.05mm |
Repeatability accuracy |
±0.02mm |
Min pitch |
0.35mm |
Air pressure |
4-6kgf/cm2 |
Power supply |
220V,50/60Hz,100W |
Dimension |
L900*W1600*H1650mm |
Weight |
About 350kg |
