the most popular Chinese commuter bus replacing the Nigerian old bus:
1. diesel engine -- YC4F115-30 - 2.659L;
2. front mounted engine, rear wheel drive;
3. manual transmission;
4. 19+1 seats, can take as many as 38 passengers including the standing persons
the most popular Chinese commuter bus replacing the Nigerian old bus
Specification / Description of the product "the most popular Chinese commuter bus replacing the Nigerian old bus":
---Basic Parameter Datas of the Chinese Commuter Bus:
| Dimenssion | Length(mm) | 6500 | Engine Data | Engine Model | YUCHAI (YC4F115-30) |
| Width(mm) | 2200 | Engine Type | Four cylinder in line, water cooled, 4stroke | ||
| Height(mm) | 2570 | ||||
| Wheel Base (mm) | 3650 | Displacement(L) | 2.659 | ||
| Wheel Tread F/R(mm) | 1750/1586 | Max. Power(KW/rpm) | 85/3200 | ||
| Overhang F/R(mm) | 740/2060 | Max. Torque(N.m/rpm) | 300/2200 | ||
| Approach/Departure (°) | 10/9 | Fuel Type | Diesel, Euro III | ||
| Performance | Chassis Manufacture | Dongfeng | Max. Speed(km/h) | ≥95 | |
| Chassis Model | EQ6650KN3AC | Max. Grade Ablitiy(%) | ≥20 | ||
| Engine Position | Front Mounted | Min. Turning Diameter(m) | ≤16 | ||
| Brake distance(m) (V=30km/h) | ≤10 | Fuel Tank Capacity(L) | 90 | ||
| Curb Weight(Kg) | 3800 | Max. Total Weight(kg) | 6000 | ||
| Axle F/R(kg) | 2300/4300 | ||||
---Other Configurations of the Chinese Cummuter bus (which can be adjusted according to different clients):
| Chassis | Clutch | single dry plate, disphragm spring | ||
| Transmission | Dongfeng 5S410, manual transmission | |||
| Rear Axle | 4.3T, ratio: 4.875 | |||
| Front Axle | 2.3T | |||
| Frame | Groove Shape crossbeam | |||
| Suspension System | Multi Leaf Spring(F 8/R 10), telescope shock absorber | |||
| Steering System | hydraulic power steering | |||
| Chassis | Brake System | dual circuit pneumatic brake, energy storage spring parking brake | ||
| Tire | bus tire 7.0-16-12 | |||
| Electric System | 24V, Single Wire, Minus Earth | |||
| Starter | Standard with the engine | |||
| Battery/Generator | 6-QA-150AH, 2pcs / Standard Genrator with the engine | |||
| Body | Body Structure | Semi-Integral load body, Steel Frame, Pre-stress Stretched Panel Skin | ||
| Interior Trimming | Soft Inner Trimming | |||
| Door& Door Pump | middle and rear pneumatic controlled door | |||
| Window | front cemented windscreen/rear cemented windscreen, push-pull side window | |||
| Floor | Driver's area: common covering. Passenger's area: plastic board with covering | |||
| Seat | 19+1, 19 plastic passenger seat, 1 adjustable driver seat | |||
| Handrail & Ring | Painted handrail | |||
| Audio & Visual | Vehicle MP3 player | |||
| Rear View System | KW20 Common rear view mirror | |||
| Lamp | Combined headlamp and round Tail Lamp | |||
| Wiper | A pair of Rain Wiper | |||
| Servcie Facility | Fire Extinguisher, fan, microphone | |||
| Other | Domestic Painting | |||
Pictures of this "the most popular Chinese commuter bus replacing the Nigerian old bus":
--- Our Chinese Cummuter Bus in Nigeria compared with the local old yellow bus:
--- Chinese Commuter Bus in different colors:
--- interior and exterior of the Chinese Cummuter Bus in Nigeria:
&
Brief introduction of "Big Group Company":
1. Our company is focusing on the the vehicle assembling project throughout the world, so far, we have successfully set up several such auto assembling plants in Syria, Ghana, Seychelles, Vanuatu for pickup, SUV, mini bus, and mini moke assembling. Anyone who is interested, contact us freely, looking forward to your cooperation.
2. Our main products:
1) Pickup (Single & Double Cabin; Gasoline & Diesel Engine; 4x2 & 4x4 drive; LHD & RHD);
2) SUV (off-road vehicle: 5 / 7 seats; Gasoline & Diesel Engine; 4x2 & 4x4 drive; LHD & RHD);
3) Van (7-8 seats, 9-15 seats, Gasoline & Diesel Engine; 4x2 drive; LHD & RHD);
4) Mini Moke (Gasoline & Electric, 4x2 drive, LHD & RHD);
5) Bus (Mini Bus, Middle bus, City Bus, and Long-Distance Bus);
6) Providing the assembling equipments and assembing technology of the above mentioned automobiles (pickup, SUV, Van, Moke and Bus) as well as the complete SKD/CKD parts.
Join us and you will see how to work with us on this business, we can also help you to establish the assembling plant in local if you are interested, both complete set of high quality mini bus parts and assembling technology are available, we have been in this business for more than 6 years, successfully in Syria, and now in Ghana, and will be in Nigeria, Angola and Jordan, looking forward to your cooperation !!!
Contact:
Lucky Peng (Ms.)
yingqingpeng at china-big dot com dot cn
Skype: chongqingbig
Whatsapp: 15223551381
