Assemble LHD/RHD China Mini Bus
- 10000 Unit / Units per Month
- Port of China
- T/T
- simple bus production line to assemble 19+1 seats up to 38 passengers mini bus from SKD to CKD
- Diesel/CNG Bus Assembly Line
- Pure Electric City Buses Cheap Shipping Container from China to Venezuela
- 39 Seats New Energy Pure Electric City Bus
- New Energy Electric City Bus SKD Assembly Line
- Search Partners for New SUV, Pickup, Mini Van Mini Bus SKD CKD Assembly
Product Details
Seats: | 11 - 20 | Emission Standard: | Euro 2 | Transmission Type: | Manual |
Steering Position: | RHD | Fuel Type: | Diesel | ||
Dimensions (L x W x H) (mm): | 6500*2200*2570mm | Place of Origin: | Chongqing, China | Brand Name: | HT |
Model Number: | CKZ6650 |
Packaging Details
safe export packages (LHD/RHD China Mini Bus)
Product Description
"Assemble LHD/RHD China Mini Bus by SKD/CKD in local" has many advantages, such as: to save customs duty; to save freight; it is easy to start; the assembling operation is very simple, from SKD to CKD much easier
Assemble LHD/RHD China Mini Bus
Description of the Mini Bus---
Technical details of this China Mini Bus:
---Basic Parameter Datas (Mini Bus):
Dimenssion | Length(mm) | 6500 | Engine Data | Engine Model | YUCHAI (YC4F115-30) |
Width(mm) | 2200 | Engine Type | Four cylinder in line, water cooled, 4stroke | ||
Height(mm) | 2570 | ||||
Wheel Base (mm) | 3650 | Displacement(L) | 2.659 | ||
Wheel Tread F/R(mm) | 1750/1586 | Max. Power(KW/rpm) | 85/3200 | ||
Overhang F/R(mm) | 740/2060 | Max. Torque(N.m/rpm) | 300/2200 | ||
Approach/Departure (°) | 10/9 | Fuel Type | Diesel, Euro III | ||
Performance | Chassis Manufacture | Dongfeng | Max. Speed(km/h) | ≥95 | |
Chassis Model | EQ6650KN3AC | Max. Grade Ablitiy(%) | ≥20 | ||
Engine Position | Front Mounted | Min. Turning Diameter(m) | ≤16 | ||
Brake distance(m) (V=30km/h) | ≤10 | Fuel Tank Capacity(L) | 90 | ||
Curb Weight(Kg) | 3800 | Max. Total Weight(kg) | 6000 | ||
Axle F/R(kg) | 2300/4300 |
---Other Configurations of the Mini Bus (can be adjusted according to different clients):
Chassis | Clutch | single dry plate, disphragm spring | ||
Transmission | Dongfeng 5S410, manual transmission | |||
Rear Axle | 4.3T, ratio: 4.875 | |||
Front Axle | 2.3T | |||
Frame | Groove Shape crossbeam | |||
Suspension System | Multi Leaf Spring(F 8/R 10), telescope shock absorber | |||
Steering System | hydraulic power steering | |||
Chassis | Brake System | dual circuit pneumatic brake, energy storage spring parking brake | ||
Tire | bus tire 7.0-16-12 | |||
Electric System | 24V, Single Wire, Minus Earth | |||
Starter | Standard with the engine | |||
Battery/Generator | 6-QA-150AH, 2pcs / Standard Genrator with the engine | |||
Body | Body Structure | Semi-Integral load body, Steel Frame, Pre-stress Stretched Panel Skin | ||
Interior Trimming | Soft Inner Trimming | |||
Door& Door Pump | middle and rear pneumatic controlled door | |||
Window | front cemented windscreen/rear cemented windscreen, push-pull side window | |||
Floor | Driver's area: common covering. Passenger's area: plastic board with covering | |||
Seat | 19+1, 19 plastic passenger seat, 1 adjustable driver seat | |||
Handrail & Ring | Painted handrail | |||
Audio & Visual | Vehicle MP3 player | |||
Rear View System | KW20 Common rear view mirror | |||
Lamp | Combined headlamp and round Tail Lamp | |||
Wiper | A pair of Rain Wiper | |||
Servcie Facility | Fire Extinguisher, fan, microphone | |||
Other | Domestic Painting |
Pictures of this "LHD/RHD China Mini Bus":
--- Made in 2015 the most popular high quality China Mini Bus in different colors:
--- interior and exterior of the 2015 popular high quality China Mini Bus in Nigeria:
-- Mini Bus Driving Cab (both Left Hand Drive Steering and Right Hand Drive Steering are available)
-- Mini Bus Plastic Seats (with two doors - front & rear)
Our company is focusing on the overseas automobile assembling project, including pickup, SUV, van, and bus, now let me introduce you the bus project as below:
Brief Introduction of this SKD/CKD Mini Bus assembling project in Nigeria (also suitable for other countries, in which the customs duty difference between CBU and SKD / CKD is large, e.g. at least 30% or so):
1) save customs duty, this is the most important factor, usually, in most of the countries, the customs duty rate for the kd parts (knocked down auto parts) is much less than the rate for the complete vehicle, the government wants to protect or develop their own industry, for example, in Nigeria, the tax rate on CBU (complete vehicle) is 35%, while only 5% for SKD, and zero percentage for CKD, this is a very good policy;
2) save other taxes in your country for importing such a vehicle, for example, to exept the VAT for 10 years, etc.;
3) save shipping cost, for promote this Mini Bus to the world, we have been thinking out one way to save the shipping cost, why? as we all know, the diesel bus shuttle is 6.5 meters long, and 2.75 meters high, 2.2 meters wide, one 40HQ container can only load 1 unit, or we can only use RORO (however, some place, RORO is not available), thus, the shipping cost for one unit is really a large amount, after discussion among our Technical Department, it is suggested to cut the front part of the Mini Bus (that is, the front "nose" part, which is not load-bearing), but with a Mini Bus shell welded, disassembling the chassis, inner trim, tyre, bumper... after calculation, if with large quantity, the average loading quantity is 1.8 units or 2 units without engine per 40HQ container. The engine and chassis, tyre... can be loaded together in one container. For our Nigerian partner, in this way, the shipping cost will be reduced by that amount for one complete Mini Bus to Nigeria on average, so it is a big cost. With this disassembling parts and loading programme, you can reduce not only customs duty but also shipping cost.
So it is more easy and simpler to start the Mini Bus assembling project from SKD Mini Bus to CKD Mini Bus and CKD longer bus.
4) Earn your own Intangible Assets: with the assembly project, you can develop and have your own auto brand, logo and also enlarge to the neighboring countries by using the preferencial tariff policy amount your communities.
5) however, to start the mini bus assembling project, it is a public project, not private, so you have to find partners who has good connection with the local government, and prepare enough working capital with your local banker and other financial organizations.
What kind of partners we are looking for?
1) Investment Power Requirement: over 1 million USD;
2) Land & Workshop Requirement: over 15000-20000 square meters land including 5000 square meter workshop at least;
3) Software Requirements: Good Automobile Sales Shannel, Familiar with Automobile Industry and Its Business;
4) Hardware Requirements on the Import Tariff: the difference gap between auto spare part CKD (completely knocked down) and CBU (complete built unit) shall be at least 30-35%, for example, import tariff on CBU is 35%, it must be 5% or zero on CKD.
-- Mini Bus Factory Workshops:
-- Mini Bus Manufacturing Procedures:
What about After-Sales Service?
We propose and provide "REPAIR & MAINTENANCE" After-Sales Service:
1) Found a professional bus "Repair & Maintenance" service company to ensure the After-Sales Service;
2) Bus spare parts supply;
3) Driving & repairing training guidance;
4) Technical advisory and training;
5) Market data feedback and disposing;
6) The most important - Technology Support.
Brief Introduction of our "Big Group Company":
1. Our company is focusing on the the vehicle assembling project throughout the world, so far, we have successfully set up several such auto assembling plants in Syria, Ghana, Seychelles, Vanuatu for pickup, SUV, bus, moke assembling. Anyone who is interested, contact us freely, looking forward to your cooperation.
2. Our main products:
1) Pickup (Single & Double Cabin; Gasoline & Diesel Engine; 4x2 & 4x4 drive; LHD & RHD);
2) SUV (off-road vehicle: 5 / 7 seats; Gasoline & Diesel Engine; 4x2 & 4x4 drive; LHD & RHD);
3) Van (7-8 seats, 9-15 seats, Gasoline & Diesel Engine; 4x2 drive; LHD & RHD);
4) Mini Moke (Gasoline & Electric, 4x2 drive, LHD & RHD);
5) Bus (Mini Bus, Middle bus, City Bus, and Long-Distance Bus);
6) Providing the assembling equipments and assembing technology of the above mentioned automobiles (pickup, SUV, Van, Moke and Bus) as well as the complete SKD/CKD parts.
Looking forward to your cooperation !!
Our Contact:
Lucky Peng (Ms.)
yingqingpeng at china-big dot com dot cn
Skype: chongqingbig
Whatsapp: 15223551381
Company Profile
We are an auto manufacturer from China searching for local cooperation partners for Auto assembly projects. Our cooperation models include turn-key project, joint venture and agreement cooperation, while our product line includes mini cars, mini trucks, pickups, SUVs, mini Moke jeeps, CNG buses (airport buses, new energy buses, electric-powered buses, and Hybrid buses) etc. We have established a lot of auto assembly factories in many countries, e.g. Syria, Egypt, Ghana, Nigeria, Angola, Bangladesh etc. Achieving a win-win by providing technology and/or investment is our core principle. Our main business includes two parts auto sales and set up overseas joint ventures factories with local partners.
Welcome to visit our factory and join us.
