Specifications
1. MATERIAL: high tensile steel2. STANDARD: Generally to B.S. 3032 table 4
3. SAFETY FACTOR: MBL equals 4XWLL
Product Description
BS3032 SMALL BOW SHACKLE WITH SCREW COLLAR PIN
| MATERIAL: | high tensile steel | |
| STANDARD: | Generally to B.S.3032 table 4 | |
| SAFETY FACTOR: | MBL equals 4 X WLL | |
WARNING: NEVER EXCEED PUBLISHED WORKING LOAD LIMIT.
| working load limit | diameter bow(mm) | width inside(mm) | diameter pin(mm) |
| WLL0.2T | 6 | 13 | 10 |
| WLL0.5T | 10 | 16 | 13 |
| WLL1T | 13 | 22 | 16 |
| WLL1.5T | 16 | 28 | 19 |
| WLL2T | 19 | 35 | 22 |
| WLL3T | 22 | 38 | 25 |
| WLL4T | 25 | 44 | 28 |
| WLL5T | 28 | 51 | 32 |
| WLL6.25T | 32 | 57 | 35 |
| WLL7.5T | 35 | 60 | 38 |
Application
Widely used in electric power, metallurgy, petroleum, machinery, railway, chemical industry, ports, mining, oil & gas, fishing, offshore, construction and other industries.
About us
1. We are Manufacturer.
2. We are specializing in various shackles, turnbuckles, hooks, binders, clamps, eye bolts and nuts, thimbles, anchor chains and stainless steel rigging.
3. Stock: Rich
4. We accept customized drawing and dimension
5. Best Quality,Competitive pricing, Speedy delivery,24 hours Service.
6. Our clients are from Europe, America, Australia, Africa, Mid East, etc.
7. We assure Each kinds of item must be strictly inspected one by one before shipment .
All finished products are not on ground.
