Fast Semi-Auto DH-CP3 LCD repair Machine Vacuum for mobile Phone LCD touch screen Refurbish
Specifications for DH-CP3 LCD seperating machine: Name: Semi Automatic Separator |
Features for LCD screen separator machine:
1. Auto heating metal plate, maximum temperature is 400 centigrade
2. Safety power system inside, avoiding the electric leakage problem
3. Anti static body material, prevent the LCD and the flex cable being damaged from the static
4. Easy installation
5. 4 stronger arms to press the touch screen glass on the plate
6. Smooth metal plate to hold the touch screen without any damaged
7. Temperature should be set to 80 centigrade to 100 centigrade, when you do the job on iPhone and galaxy series…
8. 2 bearings to last long the life of the wire you use to separate, and prevent your hands be hurt by the high temperature platform
9. Compatible for LCD or LED screen assembly
Operating Instruction:
1.Turn the power switch on.
2.Turn the temperature controller on, and set the temperature between 60 and 80 degree.
3.Wind wire on the rollers.
4.Fix the wire on the roller of the left side motor. Wind the wire from top to bottom, then adjust the steering
button to up position. Go on winding wire bypass the front two rollers. Then turn on the rotary switch. Wind the wire
about 3-5m, turn off the rotary switch.
5.Pull the wire tight, and wind the wire from bottom to top, then fix the other end on the roller of the right side motor.
Adjust the steering button down. After the wire rotary half on the wheel, turn off the rotary switch. Finally, adjust the
steering button to horizontal position.
6.Adjust the motor from the top of the skidway about 2 cm.
7.Put the LCD on the operating floor.
Packaging & Shipping
1. The machine can be delivered by DHL, FedEx, TNT, EMS, UPS.
2. By sea or by air. Please provide us your nearest port.
3. The delivery date is within 7 days after the receipt of payment. If you are in urgent need of it,please kindly tell us.
