TM-H2 Double heads 1 color plastic pad printer
TM-H2 Double heads 1 color plastic pad printer
Video link: /v_show/id_XNjM0OTg4NzEy.html
Technical parameters
Plate area |
100×100mm |
Worktable largest size |
255×120mm |
Max printing diameter |
DIM70mm |
Max printing speed |
1800pcs/hr |
Air consumption |
91litre/min(5bar) |
Power |
110/220V 60/50Hz 50W |
Dimensions |
700×360×1250mm(L×W×H) |
Weight |
80Kg |
Machine features:
1.Plastic pad printerWith microcomputer-controller, semi-automatic, utility function and the operating procedures are flexible and reliable.
2. The hardened axle can bearing made by famous processor and the SMC Pneumatic Components from Japan are adopted to reduce the repair and maintenance, so that the unit is not worn easily and service life of machine parts are extended largely.
3. Plastic pad printer has separated colloid head and is convenient for adjusting the speed of movement back and forth, and is applicable to different printing needs.
4. Base for each inking pan can be adjusted independently at X and Y angle, with accurate chromatograph and improved production efficiency.
5. The body of the unit adopts the die-cast rack of aluminum alloy and is both portable and solid.
6. The safely rubber sheet and emergency cut of system of power supply are provided so as to make unit comply with the international industrial safety standards.
7. With multilevel-controlled, and is satisfied with different requirement of the printing speed.
8. The rolls to inking, easy to install and uninstall, and convenient for cleaning.
9. Plastic pad printer is set 4-digit number auto-counter, and is convenient for recording the quantity of the printing products.
10. With self-poise oil scraper, can adjusting the thickness of steel independently, scrape oil efficiently.
11. The colloid head is not leave moulage when blank line printing, it is prevent from the printing ink to dry when we pause the machine.
12.It is setting the standard procedure and off-standard program, breakthrough the function of ordinary machine, unlimited program to procure ink and printing.
Machine accessories:
A copy of specification, one set of Allen key, one piece of cross Screw and straight Screw, one piece of scraper, one piece of fuse, 4 pieces of Screw for fixing pad, 1.5 meter of power line.
Packaging & Delivery
Packaging Details: Wooden case with international standard.
Delivery Detail: 5 days after payment.
Company Information
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2005. OEM products have been achieved CE certification.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Major market: America market.
Applications:
It mainly applies to the printing process and pre-postpress of plastic and hardware products .Our equipment is also applicable to other material as glass, ceramic, wood, leather, cloth, etc.
Involved in the industry:
Electronics, toys, gifts, clothing, stationery, cosmetics, washing products, chemicals, food, health product, pharmaceutical and packaging etc.
Advantages:
1. All the electrical components and control system are from Germany and Japan, guarantee the stable quality of the print.
2. Multi-purpose microcomputer operating panel and touch screen operation can easily achieve man-machine dialogue.
3. As high quality steel frame structure and High temperature of the lacquer that bake, so that our printer is light and solid, beautiful and practical.
Our first-class products and considerate services have won more than 80 countries, acceptance in Europe and the United States, Canada, Southeast Asia, the Middle East and other customer, and we enjoyed a high reputation in the market. We cooperate with Omron, Emerson and Ruigao light, which are the world famous enterprises.
1.Excellent quality control is one of our main principles.
2.Various style for each products and completely series pneumatic products for you to choose from.
3.Sample order & small quantity order is ok.
4.We provide OEM service, accept customer label, develop the product with your drawings or samples.
5.Any question, will be replyed within 24 hours.
