TAM-358 Manual High Pressure Gold Stamping Machine
Video link:
http://youtu.be/8v_z0V6j0KU
Technical Parameters:
Application area: papers, shoes, leather, PVC card, books, plastic parts. | ||
1 |
Model |
TAM-358 |
2 |
Product shape |
Plane |
3 |
Impression area |
300X150mm (11.8" X 5.9") |
4 |
Power |
220V |
5 |
Electrothermal Power |
1000W |
6 |
Operation |
semiauto(60degree-400degree) |
7 |
Stamping speed |
700 PCS/H |
8 |
Print head |
300X150mm |
9 |
Worktable |
350X320mm |
10 |
Pressure |
2000 kg |
11 |
Max. product thickness |
190mm |
12 |
Machine Weight |
146KG |
13 |
Machine Outline Dimensions |
620X580X770mm/68*66*82 |
14 |
Volume |
0.9CBM |
15 |
Lead Time |
6 days after payment |
16 |
SKU |
50 SET |
17 |
Packing |
plywood case |
18 |
Gross Weight |
180KG |
19 |
Payment Terms |
TT/Western Union/LC |
Characteristics:
1. Semi-auto stamping, auto foil feeding, without compressed air, leads to easy operation.
2. Stamping temperature adjustable.
3. The height of the stamping head adjustable accordingly.
4. Automatic foil feeding and rolling with adjustable function.
5. The mechanism to transmit printing ribbon uses motor reduction gear with its length being properly controlled.
6. Horizontal sliding print bed - for accurate product placement.
7. Variable motorised auto foil feed - for minimal waste and effort.
8. Flat heating element - for efficient heat transfer. Micro-adjustable pressure - for the ultimate in convenience and versatility.
