62.5kVA High best quality water cooled generator price list Details
- 300 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | Shanhua | Model Number: | HL62.5GF |
Output Type: | AC Three Phase | Speed: | 1500RPM | Frequency: | 50hz |
Rated Power: | 50kW/62.5kVA | Rated Voltage: | 400/230v 380/220V | Rated Current: | 90A |
Product Description
Specifications
- 62.5kVA High best quality water cooled generator price list Details- Cummins OEM
- 100% copper wire
- Open type
62.5kVA High best quality water cooled generator price list Details
Standby power (50HZ): 55KW / 68.7KVA
Prime Power (50HZ):50KW / 62.5KVA
DIESEL ENGINE
ENGINE SPECIFICATIONS
Engine Model :4BTA3.9-G2
Manufacturer: DCEC CUMMINS
Number of cylinders:4
Cycle:4-cycle
Air intake way: Turbocharged
Bore(mm):102 Stroke (mm) 120
Compression ratio: 17.5:1
Displacement, total (L):3.9
Engine weight,dry (kg):350
TECHNICAL DATA
Engine speed (rpm) : 1500
Exhaust temperature (°C):460
Base Output Power (kW):50
Standby Power (kW):50
Torque (Nm) : 318
Low idle (rpm):1000 ± 50
Piston speed (m/s):7.2
Engine coolant flow (L/sec):2.2
Air intake flow (L/sec):48
Exhaust flow (L/sec):130
ALTERNATOR
Alternator Model: Shanhua HLF62.5
Prime power (kW) 62.5KW
Frequency .Speed .Voltage :50 HZ ,1500 rpm,400 v
Voltage regulation:±0.5% Rated power factor:0.8
Genset Dimensions and Weights
OPEN STYLE (Overall Size L×W×H,mm ):1900*740*1200 Weight(radiator model),net,kg) :800
SOUNDPROOF STYLE (Overall Size L×W×H,mm):2800*1100*1750 Weight(radiator model),net,kg) : 1600
NOTE: This drawing is provided for reference only and should not be used for planning installation.
Contact your local distributor for more detailed information.
Control System
Work environment :
Operating temperature :-20°C~60°C Relative Humidity : 95%
Operating voltage :DC24V (range :18-30V,pressure :50V/5 mm )
General functions and features :
Control screen is small, reliable performance, simple operation, the internal circuits clear, easy detection. With automatic detection and protection features protect the engine safe and stable operation.
Multiinterface display unit work and alarm state, intuitively clear, LCD displays the parameters of diesel engines. Microcomputer can be set on the control panel input, output, alarm, delay and other parameters.
Maintenance, manual, automatic and other modes of operation. No nonnormal electricity supply automatic starting, generator fault protection off, to provide historical state records. Generator over / under voltage,
generator frequency / high frequency generator speed due to speed / overspeed, low oil pressure, high temperature, emergency stop, battery over / under voltage, over current / short circuit protection function.
Description Standard functions : Engine Control Generator Monitoring Generator Protection Engine Monitoring Clear Text Display
Shutdown :Loss of Speed Signal Alternator Under / Over Voltage Alternator Under/ Over Frequency Mains Under / Over Voltage
Mains Under/ Over Frequency Under / Over Speed Low Oil Pressure High Engine Temperature Phase Sequence Electrical (Option) Earth Fault (Option)
Warning Loss of Speed Signal Alternator Under / Over Voltage Alternator Under/ Over Frequency Mains Under / Over Voltage Mains Under/ Over Frequency Under / Over Speed Low Oil Pressure High Engine Temperature Phase Sequence Electrical (Option) Earth Fault (Option)
