Specifications
automatic production line equipmentstainless steel structure
good quality with low price
low failure rate
fast delivery
Full automatic production line equipment
stainless steel structure
good quality with low price
low failure rate
fast delivery
Device Name: Full automatic production line equipment
Equipment Model: M3-1006
Equipment Introduction of the automatic production line equipment:
Automatic production line equipment is mainly composed of 10 filling machine, Linear Capping Machine,
Vertical round bottle labeling machine to send bottles dial composed. Imported PLC program control,
filling mouth and trough materials in contact with the liquid parts are 304 stainless steel, the use of PTFE seals.
Suitable for the food, pharmaceutical, cosmetic, chemical and special industry paste filling.
Technical parameters of the automatic production line equipment:
10 filling machine
Number of filling heads: 10
Filling capacity: 0.1L ~ 0.5L
Filling in the form: piston filling
Filling speed: 50-60 bottles / hour (450 ml)
Filling accuracy: ± 1%
Gas pressure: 0.5-0.8MPa
Conveyor belt: 82 mm the POM chain piece band
Drive motor: 550W VVVF motor
Power: 1KW / 380V three-phase five-wire
Linear capping machine
Applicable cap diameter: 50-60 mm
Under cover speed: 30-50 bottles / min.
Management cover by: magnetic conveyor belt to send Gary cap
Linear Capping Machine
Applicable bottle Width: 40-90 mm
Applicable cap diameter: 30-60 mm
Production capacity: 30-50 bottles / minute
Capping motor: 550W
Vertical round bottle labeling machine
Labeling accuracy: ± 1 mm
The applicable label: 10-100 (mm) 10-300 (mm) long
Production Capacity: 60-180 bottles / minute (depending on the diameter of the bottle)
Rated voltage: 220V/50HZ
Total power: 500W
Dimensions: 1710 × 950 × 300 (mm) (L × W × H)
Total Weight: 146Kg
Our office:
Our customer and we:
how to Ship our automatic production line equipment:
You can arrange yourself or we can help to arrange.
How to Buy our automatic production line equipment:
The process is as follows: (we Accept T/T,Western Union,Paypal etc)
1. Tell us the Items details and quantity you order. we make a PI for you.
Then You pay the down payment 50% of the total amount to our company account .
(Please notice bank charge is paid by your side)
2.After we receive the down payment, we will produce the goods for you.
3.Once we finish the products , we will send you the photos to check and confirm,
4.If everything is ok, you pay the balance amount
5.After we receive the balance amount, we will arrange shipping for you.
YBJ service:
With more than 10 years of printing and packaging experience in China,
we have cooperated with many companies, especially with the European and USA countries.
All of our pakcaging product can meet European and USA high standard.
we believe only quality can make the cooperation long-term.
At the same of good quality, we also give customer good prices.
We can ensure in China, at the same quality our price is the best.
For more information of the automatic production line equipment,
please contact us.
YBJ Group is waiting for your inquiry any time.
Our sales will reply you ASAP!
