GM500 multi-biometric identification time attendance terminal adopts latest 600 platform with Face 7.0 algorithm and large capacity memory. GM500 integrated 630MHz high speed Multi-Bio processor and high definition infrared camera enables user identification in the dark environment. Face and fingerprint multi-biometric identification method will be applicable more widely. All operations of iFace are designed to be performed on the 2.8 inches TFT touch screen. Multi-model communications includes RS232/485, TCP/IP, optional WiFi or GPRS.
CPU |
Multi-Bio CPU 630 MHz |
Memory |
256M Flash, 64M SDRAM |
Hardware Platform |
XM600 Multi-Medium Development Platform |
Fingerprint Sensor |
Optical Fingerprint Sensor without film |
Camera |
High Resolution Infrared Camera |
Display |
2.8’’ TFT touch screen |
Face capacity |
500 |
Fingerprint capacity |
1000 |
Card capacity |
10000 |
Logs capacity |
100,000 |
Algorithm Version |
Face 7.0 & Finger 10.0 |
Communication |
TCP/IP,RS232/485 |
Time attendance Standard functions |
Automatic Status Switch, Self-Service Query, Work Code, T9 input, 9 digit user ID, DLST |
Access control interfaces for |
3rd party electric lock, door sensor, exit button |
Wiegand Signal |
Output |
Optional functions |
ID card ,Mifare card, Extendable Scheduled-bell, Short Massage, Web-server, Wifi,GPRS |
Power supply |
12V3A |
Verification Speed |
≤2 sec |
Operating temp |
0°C- 45 °C |
Operating Humidity |
20%-80% |
