Vertical Milling Machine

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Port Mumbai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Vertical
CNC or Not	Normal	Place of Origin	Maharashtra, India
Brand Name	Atlas Machines	Model Number	-

Product Description

Specifications

1. Quality assured
2. Timely delivery
3. Good After sales sevice

SPECIFICATIONS

MODEL	AMI-1	AMI-2	AMI -3	AMI -4
TABLE
Working Surface	1270 x 280	1400 x 330	1600 x 350	1800 x 400
Swivel	±45°	±45°	±45°	±45°
T-Slot No. / Size	3,17	3,17	3,17	4, 17
T-Slot Centre	65	80	90	90
Longitudinal Travel	650	775	950	1200
Cross Travel	205	250	305	450
Vertical Travel	380	505	545	650

FEEDS
No. of Rapid Feeds	2	2	2	2
Longitudinal Rapid Feeds / Min.	735-1065	735-1065	735-1065	735-1065
No. of Feeds	18	18	18	18
Range of Longitudinal / Cross Feed Per Minute	13 to 305	13 to 305	13 to 305	13 to 305
Range of Vertical Feed Per Miute	5 to 100	5 to 100	5 to 100	5 to 100

SPINDLE
Spindle Taper	ISO 40	ISO 40	ISO 40	ISO 40
No. of Speeds	12	12	12	12
Range of Spindle Speeds	40 to 1120 RPM	40 to 1120 RPM	40 to 1120 RPM	40 to 1120 RPM
Distance of Spindle to
Table Min. / Max.	25 / 380	25 / 505	25 / 545	25 / 600
Distance of Spindle Centre to Column Guide	300	350	375	425
Vertical Head Tilt	±90°	± 90°	± 90°	±90°
Manual Quill Travel	95	95	95	95

ELECTRICALS
Main Motor	5.0 HP	7.5 HP	7.5 HP	10HP
Feed Motor	2.0 HP	2.0 HP	2.0 HP	3.0 HP
Coolant Motor	0.1 HP	0.1 HP	0.1 HP	0.1 HP

DIMENSIONS
Overall Length	1850	2000	2100	2400
Width	1600	1750	1950	2100
Height	2080	2200	2300	2400
Net Weight in Kgs.	2600	3300	3700	5000
Gross Weight in Kgs.	2900	3600	4000	5500

All machines are supplied complete fitted with suitable electric 3 phase A/C supply complete with spare parts with wiring starter and panel bolt motorised coolant system with assembly machine lamp and arbour dia. 1 no., foundation bolts, tool box and instruction manual.
