Home > Products > Jacket Kettle > Large Electric Cooking Pot
Large Electric Cooking Pot
- 10 Set / Sets per Month
- QINGDAO
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | LONGWANG | Model Number: | JE-400A.2 |
Type: | Cooking Equipment | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
PREVIEW
Heat source of jacket kettle are transfer oil, steam, gas. It has the following advantage: big heating area, high heating efficiency, foods can be fast heated up, Uniform heating and easy to control the temperature, etc. The kettle is widely used in processing the candy, cake, drink, fruit juice, jam, conserve, dairy, can, etc; making wine; making medicine; Household chemical. As the material dissolves, disinfecting, heating, blanching, pre-cooked, prepared, cooking and enrichment purposes. But also applies to large hotels, restaurants, hotels, guest houses, restaurants, industrial and mining enterprises, authority troops, tertiary institutions and canteens, as porridge, soup, boiled dumplings, cook and stew with. For years, most of the customers think that the kettle really can improve the quality of the production, short the working time and improve the working terms.
USAGES
1. It is widely used in candy, medicine, can, drinks, etc.
2. Many restaurants or canteen are also use pot for soup, stew.
FEATURES
1. Heating medium is steam with basic pressure. Advantages of pot include large heated area, high thermal efficiency, uniform heating and easy to control temperature, etc.
2. Pot material is made of stainless steel304, to prolong service life. Meanwhile, equip with pressure gauge, safety valve and control box.
3. Capacities: 50L~1000L
4. Consist of pot body, frame, hand wheel, etc.
5. The equipment can configure the mixing system according to different craft demand.
DIFFERENT TYPES
CLASSIFY
1. According to structure types
1.1.Vertical Fixed Jacketed Kettle
1.2. Tiltable Jacketed Kettle
(The largest tiltable angle is 90 and the tilting type is manual.)
2. According to art demand
2.1. No Stirring Jacketed Kettle
2.2. Stirring Jacketed Kettle
a. The pot with stirred device is stirring through top center. The speed reducer output shaft looper connects with stirrer shaft. It’s convenient to remove and clean.
b. Two types: ordinary scraper, planetary scraper.
MODEL REFERENCE
MODEL | VOLUME (L) | HEATING AREA (m2) | INNER DIAMETER (mm) | DEPTH (mm) | WIDTH (mm) | HEIGHT (mm) | WEIGHT (kg) | DESIGN TEM (℃) |
JE-50A.2 | 50 | 0.39 | 550 | 400 | 880 | 820 | 80 | 140 |
JE-100A.2 | 100 | 0.77 | 710 | 480 | 1000 | 870 | 106 | 140 |
JE-200A.2 | 200 | 1.29 | 840 | 530 | 1050 | 915 | 121 | 140 |
JE-300A.2 | 300 | 1.34 | 930 | 600 | 1100 | 960 | 139 | 140 |
JS-400A.2 | 400 | 1.98 | 1000 | 640 | 1120 | 1050 | 193 | 140 |
JE-500A.2 | 500 | 2.3 | 1080 | 680 | 1150 | 1090 | 251 | 140 |
JE-600A.2 | 600 | 2.7 | 1200 | 790 | 1280 | 1110 | 274 | 140 |
