Tilting Electric Heating Jacketed Kettle With Mixer (Agitator)
General Introduction:
Our jacketed kettles are made of 304 stainless steel both inside and outside and have smooth and shiny appearance. It can be manually tilted by using a handle on the side making it easier and safer to pour the contents inside the pot.
The jacketed kettle is widely adopted in various food processing industries, such as sugar, sauce, curry, dishes, beverage, liquor, dairy, cake, chemical and medicine, etc., also can be used in large restaurants and canteens for boiling, cooking, frying and stewing large quantities of food.
Features:
This kind of jacketed kettle has the following features:
1. Easy to install and operate;
2. Uniform Heating;
3. Large heating area;
4. Short boiling time;
5. Easy control of heating temperature;
6. Mixing scrapers can touch the bowl thoroughly avoids burning;
7. Stirring speed is adjustable;
8. Corrosion & abrasion resistance;
9. Longer service life;
Classification of Jacketed Kettle:
By heating method:
1. Electric heating type;
2. Steam heating type;
3. Gas heating type
By configuration of the Jacketed Kettle:
1. Tilting type / vertical type;
2. With agitator / without agitator;
3. Ordinary stirring type / planetary stirring type;
4. With lid / without lid;
Technical Parameters:
Model No. |
Capacity (L) |
Heating Area (m2) |
Inner Diameter (mm) |
Depth (mm) |
Width (mm) |
Height (mm) |
Weight (kg) |
JE-50A.2 |
50 |
0.39 |
550 |
400 |
880 |
820 |
80 |
JE-100A.2 |
100 |
0.77 |
710 |
480 |
1000 |
870 |
106 |
JE-200A.2 |
200 |
1.29 |
840 |
530 |
1050 |
915 |
121 |
JE-300A.2 |
300 |
1.34 |
930 |
600 |
1100 |
960 |
139 |
JE-400A.2 |
400 |
1.98 |
1000 |
640 |
1120 |
1050 |
193 |
JE-500A.2 |
500 |
2.3 |
1080 |
680 |
1150 |
1090 |
251 |
JE-600A.2 |
600 |
2.7 |
1200 |
790 |
1280 |
1110 |
274 |
Testing by customer before delivery:
If you are interested in our products want to consult us, you can freely call us or send us Email at any time, we will be very glad to serve you. Welcome to visit our factory in Zhucheng City of China.
