Floating Buoy

Specifications

                                                                         HNF3.0 monitoring buoy

The HNF3.0 is a meteorological/oceanographic Hydrologic Monitoring buoy.This buoy suitable for measuring ocean meteorological parameters in Harbors.lakes ,and coastal area where the water depth is within 200 meters.with the max ,wind speed 36m/s,and max ,flow rate 4 knot.

The buoy is moulded from polyurethane elastomer with internal stailess steel skelton enhanced and the body filled with closed-cell flexible foam which provides the buoy with great lightness and excellent mooring capacity .The choice of material ensures no risk of corrosion as well as excellent resistance to impacts.

HNF3.0 buoy is equipped with three or four wells making the submerged sensors accessible without having to lift the buoy out of the water .In the wells the sensors are well protected during handling as well as theft and vandalism .

Specification:

diameter :3000mm

body height:4850mm

freeboard:600mm

water depth:1300mm

 Features

1>  High visibility reducing the risk of being run into and damaged by boats.

2>  Long term unattended operatin due to large solar charging and battery capacity

3>Multi-parameter and multi-application real time monitoring is feasible

4>extremely robust construction Suitable for measuring oceanographic parameters waves,currents,water quality and meteorology

5>excellent mooring capacity

6>low maintenance

7>excellent resistance to collision

8>painting according to IALA recommendations

9>Excellent sealability of the instrument capsule

10>modular structure of bolt connection easy to transport the entire buoy no magnetic

 Packaging details: loaded by tray

 Delivery time: 15 days after receiving the payment

 Company Introduction :Qinhuangdao Yaoxing Aids to Navigation Technology Co., Ltd. is a technological company which professionally manufactures all kinds of aquatic products. They have runned more than 10 kinds of marine products at present. And that includes the series of buoys, beacon, monitoring buoys and so on.
