Monitoring Buoy

Qinhuangdao Yaoxing Aids to Navigation Technology Co., Ltd. is a technological company which professionally

manufactures various kinds of aquatic products. Our company was founded in 2006 and located in the beautiful coastal

city,Qinhuangdao. With the efforts of the staffs, Yaoxing has runned more than 20 kinds of marine products at present.

And the products include the series of buoys, beacons mooring buoy etc.

Qinhuangdao Yaoxing Aids to Navigation Technology Co., Ltd. is a technological company which professionally

manufactures various kinds of aquatic products. Our company was founded in 2006 and located in the beautiful coastal

city,Qinhuangdao. With the efforts of the staffs, Yaoxing has runned more than 20 kinds of marine products at present.

And the products include the series of buoys, beacons, mooring buoy etc.

The hydrologic monitoring buoy is the equipment that can support the real-time monitoring system of water. It ismoulded from high-density elastic polyurethane with internal steel skeleton enhanced. It is equipped with solar panels and maintenance-free batteries which enable long-term unattended operation. Optional equipment includes varioushydrological and weather monitoring instruments, data acquisition units and wirelessdata transmission modules, which

automatically transmit the data to the monitoring center through the GPRS satellite. After mountingthe buoy in monitoring center, there is no need for manual operation. The monitoring information is real-time transmitted, accurate and reliable.The buoy is suitable for water where the depth is within 200m with the max wind load 36m/s and max flow velocity 4 knots.

HNF3.0 buoy is equipped with three or four wells making the submerged sensors accessiblewithout having to lift the buoy out of the water.

This reduces the operation cost because work can be done without large boats and heavy lifting equipment.

The wells can also be used for current sensors.In the wells the sensors are well protected during handlingas well as theft and vandalism.

Specification :

Body diamter : 3000mm

Solar panel specification : MAX .120*4

Battery : MAX.800AH

Mooring load :1000kg

Buoy weight :1000kg

Wells number : 4pcs

 Packing in exporting case, or as the customer required

Features

• Multi-parameter and multi-application real-time monitoring

• Long-term unattended operation due to large solar charging and battery capacity

• High visibility reducing the risk of being run into and damaged by boats

• Extremely robust construction

• Suitable for measuring oceanographic parameters, waves, currents, water quality and meteorology

• Excellent mooring capacity

• Low maintenance

• Equipped with Radar-Refl ector

• Excellent resistance to collision

• Painting according to IALA Recommendations
