Good Quality Plastic Materials Screw Vacuum Loader
US$ 1,000 - 1,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
material screw loader
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Plastic Materials Screw Loader in Hot SaleUS$ 1,000 - 1,500MOQ: 1 Set -
Plastic Screw Loader for SaleUS$ 1,000 - 1,500MOQ: 1 Set
-
Good Quality Screw Loader for PelletUS$ 1,000 - 1,500MOQ: 1 Set
-
Stainless Steel Screw Loader Used for Loading GranulesUS$ 1,000 - 1,500MOQ: 1 Set
-
Auto Plastic Materials Screw Loader for SaleUS$ 1,000 - 1,500MOQ: 1 Set
Condition
New
Application
material screw loader
Place of Origin
Guangdong, China
Brand Name
LongHe
Model Number
SS-3M
Voltage
380v
Power(W)
1500w
Dimension(L*W*H)
2800x1300x2600mm
Weight
150kg
Certification
ISO9001 /CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Plastic Screw Loader
Work Principle:
Screw Feeding Machine is driven by motor to move the cycloidal reducer and pass to spiral conveyor ,press the material forwarding through screw rotation,and generate forwarding push to the material,and the matericals are fed from the inlet and then conveyed to the outlet through the spiral conveyer.The machine can be used for automatically feeding materials for mixer and injection moulding machine which have certain requirement on height.
Properties:
CY-T1 Vibrating Spiral Feeding Machine can lift various power materials,and the material tank and rope are made of stainless steel;
The materials feeding motor and vibration motor are controlled with independent switches,and the vibration range is adjustable,the entire screw can be conveniently disassembled and cleaned.
The machine features automatic materials feeding and automatic stop(for independent use,install the control system of our company for achieving automatic feeding function)
The screw and the material tank and chamber have soft connection with easy disassembly,the lower part of the matrerial canister have flexible door ,forwarding and reserving rotation switch,convenient for cleaning.
The material chamber is installed with vibration motor ,and the materials can easily enter into the spiral.
TECHNICAL PARAMETERS:
| Model | Lifting Capacity (kg/h) | Material Tank (kg) | Upper Material Heig t (mm) | Motor power (kw) | Dimension (mm) | Weight (kg) |
| ss-3M | 1000-3000 | 50-100 | 1900 | 1.5 | 2800x1300x2600 | 150 |
Product picture:
