Help CenterTitanium Full Liquid Evaporator Tube for Heat Exchange
Related Products
-
Gr2 Titanium Strengthen Condenser TubeUS$ 26 - 75MOQ: 200 Kilograms -
Titanium Strengthen Condenser TubeUS$ 26 - 75MOQ: 200 Kilograms
-
Titanium Fin Tube For Space EngineeringUS$ 26 - 75MOQ: 200 Kilograms
-
Titanium Integral Low Finned TubesUS$ 26 - 75MOQ: 200 Kilograms
-
Titanium Bimetal Extruded Finned Tube Heat ExchangerUS$ 26 - 75MOQ: 200 Kilograms
Specifications
Titanium finned tube(Gr1,Gr2)Base tube:titanium tube
Outside diameter:25-219mm
Length :less than 18000mm
W.T.:1.5-25mm
Titanium full liquid evaporator tube is processed the top into holes shape,using titanium as material.
Titanium and titanium alloy high efficiency heat exchange tube
Titanium full liquid evaporator tube is processed the top into holes shape,using titanium as material. Forming cavity among spiral fins increases vaporization core needed when heat transfering and raises heat transfering efficiency outside the tube. It can be processed into spiral fins inside the tube and increases heat transfer area, forms secondary flow of turbulance, and it increases heat transfer efficiency , so the total heat transfering efficiency is raised largely. Titanium tube can be used in bad water quality, for example, polluted wayer and seawater, or used in the occasions which requires the tube have longer application life and higher safety, because its strong corrosion resistance.
Titanium Full liquid Evaporator tube Parameter
| bare tube | Processing section outside Parameter | Processing section inside Parameter | ||||||
| O.D | Thk | O.D | Fin height | Fin Bottom Thk | Fpi | Inner Fin Height | Inner Fin No | Helix angel |
| 19 | 1.2 | 18.75 | 0.58 | >0.65 | 33 | 0.28 | 30 | 45 |
| 19 | 1.3 | 18.80 | 0.58 | > 0.70 | 33 | 0.28 | 30 | 45 |
We can process according to customer's required drawing.
