Digital Optical Fiber 2 Channel Video Converter Analog Digital Video Multiplexer
Features
1. High- speed frequency division multiplexing technology is adopted ,so that several channels of signals can be multiplexed without transmission delay or interference.
2. Built-in video adjusting button in the transmitter can cooperate with different video cameras.
3. with energy-saving sircuit to achieve best energy efficiency ratio
Specifications
Video performance
u Video Channel: 2
u Video bandwidth: 0–8MHz
u Differential gain: < 1 (typical)
u Differential phase: < 0.5°(typical)
u Field tilt: < 0.5 (MAX)
u SNR: > 60dB
u Input/ Output Impedance: 75Ω (unbalanced)
u Input/ Output Volt: 1.0Vpp(typical)
Data
u Channel: 1, Reversed
u Data Rate: 0~180Kbps/channel
u Selectable RS-232/RS-422/RS-485
u Connector: RJ45
Optical performance
u Transmission wavelength: 1310nm
u Optical interface: FC/SC/ST-PC
u Transmitting power: -4dB
u Receiving sensitivity: -24dB
u Optical dynamic range: 18dB
Audio
u Stereo audio
u Audio Input: unbalanced, 600Ohms
u Digitization: 16bit@48k
u Frequency: 10Hz to 20KHz
u SNR: >70Db
u Connector: RCA
Other Parameters
u Operating temperature: -40°C - +75°C
u Operating Humidity: 0 - 95 (non-condensing)
u Power consumption: 1.8W @ DC5V
u Dimension: 434*66*200(mm) Standalone
u weight: 0.5kgs
u Mean Time Between Failures (MTBF): >100000 Hrs
