Best Quality Product Video Balun 450-650M CCTV Balun LLT-201C (Enhanced)
Features:
1.Compact size and easy installation |
2.Surge/Lighting Protection |
3.Interference Suppression/ Noise Filtering |
4.Full-motion CCTV video at distances up to 450-650m when used with any passive transceiver |
5.Up to 1500m with any active UTP video receiver |
6.Male BNC allows connection directly to the camera or DVR |
tem: |
|
Video Balun LLT-201C |
Frequency response: |
|
DC to 8MHz |
|
||
Attenuation: |
|
0.5dB typ |
|
||
CMRR: |
|
60dB typ |
Video format: |
|
NTSC, PAL and SECAM |
Connector: |
|
Male BNC |
Impedance: |
|
BNC: 75 ohms |
Terminal: 100 ohms | ||
Network Wiring: |
|
One Unshielded Twisted-Pair 24-16 AWG (0.5 ~ 1.31mm) |
|
||
Category Type: |
|
5 or better |
|
||
Impedance: |
|
100 ± 20 ohms |
|
||
DC Loop Resistance |
|
52 ohms per 1000 ft |
|
||
Differential Capacitance: |
|
19 pF/ft max ( 62pF/m max) |
Working temperature: |
|
-20°C ~ 75°C |
Storage temperature: |
|
-30°C ~ 85°C |
Humidity: |
|
0% ~ 95% RH |
Transient Immunity: |
|
per ANSI / IEEE 587 C62.41 |
Package: |
|
100 pairs/carton box |
Warranty: |
|
One Year |
Shenzhen Yongjiasheng Technology Co.,LTD. is a direct supplier of security cameras(CCTV,network IP,and AHD),video surveillance systems,and CCTV equipment (Closed Circuit Television ) for home, business and government.In addition to CCTV cameras and systems,we also manufacture network IP cameras,AHD cameras,and hundreds of video surveillance accessories.Most of our surveillance systems include DVR viewer software for Windows and Mac PCs,as well as mobile surveillance viewer apps for iphone, ipad,and Android devices.We offer many complete systems that are pre-configured and easy to install.
Our security cameras provides the best customer service & technical support in the industry.We also strive to provide the most competitive pricing possible on surveillance systems,security cameras,surveillance equipment,and DVR cards.
The function of the CCTV Video Balun is to allow the traditional 75-ohm coaxial video cable to be replaced by Category 5E/6 (or better) twisted pair in the CCTV security and surveillance environment, thereby allowing CCTV camera and monitoring equipment to be deployed more cost-effectively using structured cabling techniques.
If any problem,pls feel free to contact us via:
Email : sales10 (@)
Skype :sales10 (@)
Whatsapp:+86 136 2024 9377
Trade Manager: cn1512695796
Tel : 0086-0755- 88606011
Mobile:0086- 136 2024 9377
Contact: Jenny Lin
