Automatic Ice Block Making Machine For Edible Ice

Automatic Ice Block Making Machine For Edible Ice photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Capacity:
5,000kg daily
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Capacity 5,000kg daily
Place of Origin Guangdong, China
Brand Name CBFI
Model Number ABI50
Ice Shape Ice Block
Voltage 380v/3p/50HZ
Power(W) 14.6KW
Dimension(L*W*H) 4560*1380*1150
Weight 1700KG
Certification CE
Warranty 12months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Ice Block Making Machines
*CE approved
*No need to repair or replace refrigerant evaporator
*Easy installation and operation

Automatic Ice Block Making Machine For Edible Ice



Automatic Ice Block Making Machine For Edible Ice



Automatic Ice Block Making Machine For Edible Ice

Automatic Ice Block Making Machine For Edible Ice

  1. CE approved.
  2.  High quality. Bitzer compressor refrigeration system, Danfoss refrigeration components, Siemens PLC control   panel.
  3.  Good craft work and qualified components. At least 30 years service life.
  4.   Power saving and high-efficiency.
  5.    Edible block ice for human consumption, sanitary and clear.
  6.   Automatic operation, one worker to handle.
  7.  Containerized type, flexible in transportation and application.
  8. Automatic Ice Block Making Machine For Edible Ice Ice Forming (in ice making molds)Automatic Ice Block Making Machine For Edible IceInsulation layer of ice making molds
Automatic Ice Block Making Machine For Edible Ice
Ice Dropping (on special contact convey device)

Automatic Ice Block Making Machine For Edible Ice





Automatic Ice Block Making Machines Features:

Automatic Ice Block Making Machine For Edible Ice

Material:

The material of automatic ice block making machines is aluminum alloy plate. The whole process of ice forming is sanitary and clean and it can reach the edible standard on the condition that the supplying water is edible.

Automatic Ice Block Making Machine For Edible Ice

Faster ice falling: On ice falling, automatic ice block making machines is 1.5 times faster than brine system, ice can fall off within 25-30 minutes.



Convenient ice fetching: When ice block forms, it will automatically drop on a special ice contact convey device from the ice molds. It needn't crane or other hoist equipment to fetch ice. So it reduces the investment cost and saves more space.



For containerized automatic ice block making machines, it is very easy for transportation and installation, if you don't have a suitable place to put the machine, then we recommend you to make containerized one, because you don't need to re-build a factory again.

1) In a 20 GP container, the maximum daily capacity is 5tons .

2) In a 40 HQ container, the maximum daily capacity is 12tons.



Automatic Ice Block Making Machine For Edible IceAutomatic Ice Block Making Machine For Edible IceAutomatic Ice Block Making Machine For Edible Ice



If you are interested in our products, please contact us. We will get back to you within 24hours after getting your inquiry.



Note: in your inquiry, pls kindly inform me the information below:

1. What's the daily production of the machine do you want? We can offer from 1ton to 100ton.

2. What's the weigght for each ice block? We can design at 2.5kg, 5kg, 10kg, 15kg, 20kg, 25kg, etc.

3. What's your voltage for running the machine? Our standard one is 380V/3Phase/50Hz.
