XY-4F360 Four rolls rubber calender/conveyor belt calender for coating rubber and fabric
Specifications
1) Roll-extrusion for rubber-sheet.
2) Sticking and friction rubber of fabrics.
Application
1)This machine is mainly used for both rubber and plastic material's sheeting and rubber friction of textile or fabric.
2)Various kinds of rubber and plastic products, just as:
tyres, shoes, handbags, latex gloves,sport balls, mousepad,conveyor belts,rubber sheets & tiles, rubber band, seals,
insulation boards, PVC film,luggage fabric,etc.,
Features
1. The roller is made of chilled cast iron alloys,whose work surface has high hardness,wear-resistance and durable life.
Steem,cooling water and heat-conducting oil can pass into the roller's cavity, so that the working temperature can be
adjusted in order to meet the technological requiements.
2. Roll spacing can be adjusted both by manual or electric mode.
3. Roller bearings lubricatting can adopt drier oil or dilute oil.
Technical Specification
|
Specification Type |
Roller dia*length (mm) |
Mid-roller liner Velocity (m/min) |
Min- Thickness (mm) |
Calendering Width (mm) |
Motor Power (kw) |
Overall dimension (mm) |
Weight (t) |
XY-4F300 |
300*900 |
0~17 |
≥0.20 |
≤500~700 |
37 |
4300*1400*2300 |
8 |
XY-4F360 |
360*1120 |
0-23 |
≥0.20 |
≤700~1000 |
55 |
4700*1700*2400 |
13 |
XY-4F400 |
400*1400 |
0-22 |
≥0.20 |
≤1000~1200 |
75 |
5500*1860*2510 |
16 |
XY-4F450 |
450*1500 |
0-25 |
≥0.20 |
≤1000~1300 |
110 |
6450*2300*3300 |
30 |
XY-4F560 |
560*1700 |
0-31 |
≥0.20 |
≤1300~1400 |
160 |
7000*2600*3860 |
50 |
XY-4F610 |
610*1730 |
0-30 |
≥0.20 |
≤1500 |
200 |
7500*3700*4000 |
58 |
Container or as customer's requirement
Our company has its own factory which is specified in manufacturering all kinds of rubber machinery
nearly 30 years history (since 1984).
We have advanced measuring methods, sound quality assurance system, and experienced engineering team. We mainly produce internal mixer, open type mixing mill, roll calender, rubber extruder, rubber strainer,
rubber refiner and so on. Our products sell well around the world, such as Europe and the United States,
South America, Southeast Asia, Japan, etc.
What's more, we have TÜV and BV certification reports about our company and factory, welcome
you to download or get them from me directly.
With spirit of ‘quality first, reputation oriented’, we warmly welcome all friends from home and abroad.
View of Factory
1. Our guarantee period is one year, after this period,if you have any questions, please feel free to contact us, we will try our best to help you.
2. If you need the certification of our machine(eg:CE etc.), we will do it for you.
3. Our engineers are available to install and debug the machines overseas.
4. We can design and manufacture the machine according to your special reqirements.
1. Are you manufacturer?
Yes, we are BV approved rubber products manufacturer in China.
2. Can you design new product for us?
Yes,we have a professional development team that make new products according to your requirements.
3. What’s your payment term?
T/T, L/C.
4. How long is your guarantee?
One year (Calculated from the equipment arrives at the customer’s side.).
5. How to contact us ?
You can click 'send' now.
If you want to know more information about our products welcome to contact us in
any time, and welcome to our factory!
