X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer

X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer thumbnail-1
X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer thumbnail-2
X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer photo-1
X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer photo-2
US$ 20,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rubber Kneader
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Wuxi Jufenglong International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rubber Kneader
Place of Origin Jiangsu, China
Brand Name Shentong
Model Number X(S)N-75
Voltage 380V(designed as different countries)
Power(W) 110kw
Dimension(L*W*H) 3550mm*2560mm*3220mm
Weight 10t
Certification ISO
Warranty 1 Year
After-sales Service Provided Overseas third-party support available

X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer





Specifications

High safty
Environmentally friendly

Low energy cost



Product Description

 X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer





Features

1. This equipment possesses temperature and time-control system, can be operate easily and accurately to achieve

    effective integration solution



2. Tilt-able mixing chamber and mechanical shaft sealing design for easy cleaning and colour changing.



3. About 6-10 minutes mixing time per batch, its efficient is 2 times of wheel type mixer.



4. Pressure sealed mixing chamber to essure the quality of mixed material and also prevent environment pollution.



5. This machine is solid and easy for operation and maintenance,low malfunction, save both time and power.



Technical Specification

Technical Specification

Type

75L

Mixing chamber volume

75L

Main motor power

110kw

Tilting motor power

3.75kw

Diameter of cylinder

350mm

Dust collector motor power

1.5kw

Tiling angle

140°

Feed mode(F/R)

F/B

Steam/cooling shift mode

automatic

Shipping volume

29m³

Equipment weight

10t

Install dimension

3550mm*2560mm*3220mm

Mixing shaft forward speed

38/32 rpm

Mixing shaft backward speed

29/25rpm



Packaging & Shipping

  Wooden case, shipping container



Company Information



Our company has its own factory which is specified in manufacturering  all kinds of rubber machinery nearly 30

years history (since 1984).



We have advanced measuring methods, sound quality assurance system, and experienced engineering team.

We mainly produce internal mixer, open type mixing mill, roll calender, rubber extruder, rubber strainer,

rubber refiner

and so on. Our products sell well  around the world, such as Europe and the United States,South America,

Southeast Asia, Japan, etc.



What's more, we have TÜV AND BV certification reports about our company and factory, welcome you to

download or get them from me directly.



With spirit of ‘quality first, reputation oriented’, we warmly welcome all friends from home and abroad.



View of Factory

X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer

X(S)N-75 High Quality Rubber and Plastic Kneading Machine, Rubber Kneader, Rubber Banbury Mixer



Our Services



1. Our guarantee period is one year, after this period,if you have any questions, please feel free to contact

us, we will try our best to help you.



2. If you need the certification of our machine(eg:CE etc.), we will do it for you.



3. Our engineers are available to install and debug the machines overseas.



4. We can design and manufacture the machine according to your special reqirements.





FAQ

1. Are your company a trading one or a factory?



   Factory + trade (integration), 30 years focusing on test instruments field, 3 years exporting experience.



2. Can you design new product for us?



    Yes,we have a professional development team that make new products according to your requirements.



3. What’s your payment term?



    T/T, L/C.



4. Do you have any certificate of your products?

    Yes, CE, BV, TÜV.

5. Do you have any certificate of your company?

    Yes, BV, TÜV.


6. How long is your guarantee?


   One year (Calculated from the equipment arrives at the customer’s side.).
