Good Quality Wire Rope Pulling Hoist 0.8 Ton

Name: Good Quality Wire Rope Pulling Hoist 0.8 Ton
Brand: FEIDIAO
SKU: 120565633
Availability: InStock

US$ 46.89 - 262.89 MOQ: 10 Pieces

Key Specifications

Condition:

New

Place of Origin:

Anhui, China

Brand Name:

FEIDIAO

Tongling Shendiao Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or other China Ports

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Anhui, China

Brand Name FEIDIAO

Model Number WSH-A

Usage Construction Hoist

Power Source Lever

Sling Type Wire Rope

Maximum Lifting Weight 5.4T

Maximum Lifting Height 20m

Lift Speed Hand

Certification CE & ISO9001

Warranty 1 Year

WSH-A good quality wire rope pulling hoist 0.8 ton Features:
1)Capacity from 0.8T to 3.2T
2)High quality aluminium body

3)Overload protection system ensures safety in operation

4)Tube handle length is adjustable, so it is very convenient to regulate the hand force according to the lifting force.

5)Widely used for lifting, pulling, tensioning, and tightening in many areas

6)Easy operation, convenient maintenance

7)Get Certificate of ISO9001

8)The static test is 4 times of capacity, and running test is 1.5 times of capacity.

Model	WSH-0.8A	WSH-1.6A	WSH-3.2A
Rated capacity t	0.8	1.6	3.2
Standard lift m	20	20	20
Test load t	1.2	2.4	4
Rated forward handpower N	341	400	438
Rope diameter mm	φ8.3	φ11	φ16
Rated forward travel(Swing it front and backward) mm	≥52	≥55	≥28
Net weight kg	6.4	12	23
