Grain Processing Machinery Flour Mill Mesh
US$ 0.25 - 20
MOQ: 30 Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Shangshai
Model Number:
SS-R02
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin or other ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
58GG Wheat Milling Flour Mesh 100 Micron Nylon Filter MeshUS$ 0.25 - 20MOQ: 30 Meters -
Flour Mesh/flour Sieve Mesh/ Fine Flour MeshUS$ 0.25 - 20MOQ: 30 Meters
-
16 GG Flour Mesh/flour Sieve /flour Sieve MeshUS$ 0.25 - 20MOQ: 30 Meters
-
40 GG Flour Mesh/flour Sieve /flour Sieve MeshUS$ 0.25 - 20MOQ: 30 Meters
-
60 GG Flour Mesh/flour Sieve /flour Sifter MeshUS$ 0.25 - 20MOQ: 30 Meters
Place of Origin
Hebei, China
Brand Name
Shangshai
Model Number
SS-R02
Usage
Other, flour filter
Type
Other
Material
Polyester
Hole Shape
Square
Filter Rating
17%-49%
Thickness
46-620um
Length
customized
Width
customized
Specifications
1. food grade nylon or polyester flour mesh.2. standard size and long service life.
3. factory price.
4.samples be provided.
Product Description
different types of flour sifter mesh for milling
PET-GG Series:
Plain weave,mono filament and double filament.
Material including polyester and nylon(PA6 and PA66).
Widely used in milling industry,such as flour milling, corn milling, and other grains milling.
Mainly used for gritting gauze for coarse and scalping sieves.
PET-GG Series Specification:
| Flour Mesh Specifications PA-GG | |||||||
| Specification | Mesh Opening | Thread Diameter (um) | Base (cm) | Mesh count (/inch) | Open Area(%) | Square Meter/g | |
| PA-10GG | 2000 | 550 | 3.9 | 9.9 | 61.5 | 237.3 | |
| PA-12GG | 1800 | 450 | 4.4 | 11.2 | 64 | 180 | |
| PA-14GG | 1600 | 400 | 5 | 12.7 | 64 | 177.8 | |
| PA-15GG | 1400 | 400 | 5.6 | 14.2 | 60.5 | 197.5 | |
| PA-16GG | 1300 | 350 | 6.1 | 15.5 | 62.1 | 165 | |
| PA-18GG | 1188 | 350 | 6.5 | 16.5 | 59.7 | 177 | |
| PA-19GG | 1080 | 350 | 7 | 17.8 | 57 | 190.4 | |
| PA-20GG | 1000 | 300 | 7.7 | 19.6 | 59.2 | 153.8 | |
| PA-22GG | 950 | 300 | 8 | 20.3 | 57.8 | 160 | |
| PA-24GG | 850 | 300 | 8.7 | 22.1 | 54.6 | 173.9 | |
| PA-26GG | 800 | 300 | 9.1 | 23.1 | 52.9 | 181.8 | |
| PA-27GG | 750 | 250 | 10 | 25.4 | 56.3 | 138.9 | |
| PA-28GG | 710 | 250 | 10.4 | 26.4 | 54.7 | 144.7 | |
| PA-30GG | 670 | 250 | 10.9 | 27.7 | 53 | 151 | |
| PA-31GG | 610 | 250 | 11.6 | 29.5 | 50.3 | 161.5 | |
| PA-32GG | 600 | 250 | 11.8 | 30.0 | 49.8 | 163.4 | |
| PA-34GG | 560 | 220 | 12.8 | 32.5 | 51.5 | 137.9 | |
| PA-36GG | 530 | 220 | 13.3 | 33.8 | 49.9 | 143.4 | |
| PA-38GG | 500 | 220 | 13.9 | 35.3 | 48.2 | 149.4 | |
| PA-40GG | 475 | 200 | 14.8 | 37.6 | 49.5 | 131.7 | |
| PA-42GG | 450 | 200 | 15.4 | 39.1 | 47.9 | 136.8 | |
| PA-44GG | 425 | 200 | 16 | 40.6 | 46.2 | 142.2 | |
| PA-45GG | 400 | 180 | 17.2 | 43.7 | 47.6 | 124.1 | |
| PA-47GG | 375 | 180 | 18 | 45.7 | 45.7 | 129.7 | |
| PA-50GG | 355 | 150 | 19.8 | 50.3 | 49.4 | 99 | |
| PA-52GG | 335 | 150 | 20.6 | 52.3 | 47.7 | 103.1 | |
| PA-54GG | 315 | 150 | 21.5 | 54.6 | 45.9 | 107.5 | |
| PA-56GG | 308 | 150 | 21.8 | 55.4 | 45.2 | 109.2 | |
| PA-58GG | 300 | 150 | 22.2 | 56.4 | 44.4 | 111.1 | |
| PA-60GG | 280 | 150 | 23.3 | 59.2 | 42.4 | 116.3 | |
| PA-62GG | 275 | 150 | 23.5 | 59.7 | 41.9 | 117.6 | |
| PA-64GG | 265 | 150 | 24.1 | 61.2 | 40.8 | 120.5 | |
| PA-66GG | 250 | 120 | 27 | 68.6 | 45.7 | 86.5 | |
| PA-68GG | 243 | 120 | 27.5 | 69.9 | 44.8 | 88.2 | |
| PA-70GG | 236 | 120 | 28.1 | 71.4 | 43.9 | 89.9 | |
| PA-72GG | 224 | 120 | 29.1 | 73.9 | 42.4 | 93 | |
| PA-74GG | 212 | 120 | 30.1 | 76.5 | 40.8 | 96.4 | |
| Remark:The above data is theoretical and for your reference only. | |||||||
PET-XX Series:
With high extraction, and quality can meet to FDA standard.
Mesh opening can reach 80micron,can be used for ultra fine flour milling.
Including nylon,polyester and stainless materials,standard width127cm/145cm/165cm
also can be made as your request.
Mainly used for soft wheat and rye.
PET-XX Specifications:
| Flour Mesh Specifications PET-XX Series | ||||||
| Specification | Warp/weft (cm) | Mesh Opening(um) | Thread Diameter(um) | Tram Silk (um) | Open Area(%) | |
| PET-3xx | 24.0/25.0 | 300 | 100+2*60 | 100 | 54 | |
| PET-4xx | 25.5/26.5 | 280 | 100+2*60 | 100 | 53 | |
| PET-5xx | 27.5/29 | 250 | 100+2*60 | 90 | 51 | |
| PET-6xx | 32/34 | 214 | 90+2*60 | 90 | 49 | |
| PET-7xx | 33/36 | 199 | 80+2*60 | 80 | 48 | |
| PET-8xx | 36/40 | 181 | 80+2*60 | 70 | 46 | |
| PET-8.5xx | 40/43.5 | 160 | 70+2*60 | 70 | 44 | |
| PET-9xx | 43/48 | 146 | 70+2*60 | 64 | 44 | |
| PET-9.5xx | 43.0/50.0 | 140 | 60+2*60 | 60 | 43 | |
| PET-10xx | 49/52 | 130 | 60+2*48 | 64 | 44 | |
| PET-10.5xx | 48.5/54.0 | 125 | 60+2*48 | 60 | 40 | |
| PET-11xx | 53/60 | 120 | 60+2*48 | 48 | 42 | |
| PET-12xx | 55/63 | 112 | 60+2*48 | 48 | 40 | |
| PET-12.5xx | 56.0/64.0 | 106 | 60+2*40 | 48 | 40 | |
| PET-13xx | 58/68 | 100 | 60+2*48 | 48 | 58 | |
| PET-14.5xx | 62.5/71.5 | 90 | 48+2*40 | 50 | 37 | |
| PET-15xx | 65/74 | 88 | 48+2*40 | 48 | 34 | |
| PET-17xx | 68.0/81.0 | 80 | 48+2*40 | 43 | 35 | |
| PET-20xx | 70.0/84.7 | 75 | 48+2*40 | 43 | 34 | |
| PET-21xx | 74.0/87.7 | 71 | 48+2*40 | 43 | 33 | |
| PET-25xx | 78.0/94.0 | 63 | 40+2*40 | 43 | 30 | |
|
Remark:The above data is theoretical and for your re
