Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Energy System > Good Quality High Power Solar Home Solar Lighting System

Good Quality High Power Solar Home Solar Lighting System

Name: Good Quality High Power Solar Home Solar Lighting System
Brand: Sunnysam
SKU: 120521027
Availability: InStock

Good Quality High Power Solar Home Solar Lighting System thumbnail-1

Good Quality High Power Solar Home Solar Lighting System photo-1

US$ 51.00 - 100.00 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Sunnysam

Model Number:

SH-10W

Contact Supplier Request Quote Chat Now

Shenzhen SunnySam Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Sunnysam

Model Number SH-10W

Specification Mini

Application Home

Output Voltage (V) 18V

Load Power (W) 6~16W

Solar Power (W) 10KW

Work Time (h) 8-24 HOURS

Specifications

home solar lighting system Optional Function: FM radioMP3 Audio( input by USB disk)
Solar Power (W): 10w
Work Time (h): 10h
Lead-acid battery:12v/7A

Solar pane	10W/18V
Controller	12V/7A
Battery	12V7AH
Weight	19.8KG
Working time	20 hours
Fully charge time from solar panel	12hours

Mini LEProduct pictures:

Good quality high power solar home solar lighting system

Optional Function: FM radioMP3 Audio( input by SD card and USB disk)

Specifications

1. Solar power system

2. Solar energy

3. Low cost

4. Quite

5. Environmental friendly, No emission

1. Features

1. Solar powered. Invert cost-free sunlight into power without consuming oil, gas, or coal. Improve life in area out of electricity network.

2. Durable, easy for transportation with appealing appearance. Made of polycrystal (monocrystal) high-efficient solar panel and toughened glass and framed by aluminum.

3. Equipped with LED display monitoring instant status of system.

4. Highly operable input and output system, requiring no adjustment for installation.

5. Equipped with maintenance-free storage battery, with protection from over-charge, over-discharge, over-load, and short circuit.

6. 4 output ports at 12V, 1 USB ports at 5.0V/2.0A.

7. Quite, fear-free from vibration and dust, environmental friendly. This system is definitely your first choice of green power supply where there is no electricity network.

2. Technical Specification

1. Solar panel: 10W/20W (polycrystal / monocrystal)

2. Storage batter capacity: 12V7AH/ 12V17AH

3. Controller capacity: 12V/7A

4. Operating time capacity: depends on actual load

5. Operating temperature: -20°C-60°C.

6. Size: 225MM*85MM*185MM

7. Net.: 5.8KG(7AH)9.8KG(17AH)

8. Useful life: ≥500 cycles of full charge and full discharge of the built-in battery.

9. Output Interface: 4 ports with output at 12V/1A, 1 USB Port with output at 5.0v/2A

Model	DMD-10
Solar panel	10W/18V
Controller	12V/7A
Battery	12V7AH (maintenance free sealed lead acid storage battery)
Intelligent control	PCBA
Output voltage	DC12.0V(4Pcs) USB5V(1Pcs)
Size	225MM85MM185MM
Weight	5.8KG(7AH) 9.8KG(17AH)
Panel Size	350M290M18MM(10W)
Fully charge time from solar panel	12hours
Working time of 3W LED Light	20 hours (7AH)
Accessory	4Pcs * 3W LED Bulb 5m Wire cable (17AH) 1Pcs *USB charger connector
20 feet container	1140 pcs(7AH)

3. Operating Instructions

1. Charging: place the solar penal exposed to direct sunlight; insert the plug of the solar penal into power outlet on the main device. Battery indicator illustrated by ‘High’,’ Middle’ and ‘ Low’ shows charging status as well as how much charge is left in the battery. Charging from other electricity source is optional.

2. Using with load: the system has three outputs and protection from overload and short circuit. In case of overload and short circuit, battery indicator keeps fleshing. Lifting overload by lowering the actual load will resume operation of the device. When batter power is low, battery indicator appears red as well as ‘Low’. Timely recharging resumes operation of the device and prolongs useful life of the battery. If possible, connect the main device to solar penal permanently.

3. USB output is 5.0V/1A, usable for digital products including mobile phones and cameras. Due to the variety of digital products, please prepare your own USB connection cables.

4. Product schematic

1. Solar panel input

2. DC power

3. 5V USB output

4. Power meter

5. 12V output

5. Disclaimer and Trouble shooting

1. Dismantling and modifying without permission are prohibited. Our company takes no responsibility for any intentional damage or any damage resulting from the abovementioned prohibited behavior and improper use.

6. Support Wholesale online

All item of our solar led light support wholesale oneline.
