Various 12v Adjustable Power Transformer

Various 12v Adjustable Power Transformer thumbnail-1
Various 12v Adjustable Power Transformer photo-1
US$ 55 - 60 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WH
Model Number:
WH-200w
Contact Supplier Request Quote Chat Now
Zhejiang Weihao Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name WH
Model Number WH-200w
Output Power 201 - 300W
Output Type Single
Size 105*95*56 mm(L*W*H)
Weight 0.75kg
Input Voltage 110V/230V, 12V
Output Voltage 12V
Type DC/AC Inverters
Output Frequency 50/60Hz±3

Specifications

12v adjustable power transformer
1.CE Standard, High Quality
2.Experienced power inverter manufacture
3.Soft Start
4.CE RoHS

12v adjustable power transformer





Products Description :
modified sine wave inverter superior quality true sine wave output, it is designed to operate popular power tools and sensitive loads. Connect WH 200 modified sine wave inverter with battery terninals,then you can get AC power for your appliances,the AC output identical to, and in some cases better than the power supplied by your utility.


The inverter is equipped with numerous protection features to guarantee safe and trouble-free
Protection Function:
·Low voltage alarm & Shut down
·Over voltage protection
·Overload protection
·Over temperature protection
·Short circuit protection
·Reverse Polarity protection
·Soft start
·Auto.reset after being in protected

Product parameters

Model

WH200  (12V)

Output

Continual Power

200 Watt

Peak Power

400 Watt

Output Waveform

Modified Sine Wave

Output Frequency

50Hz/60Hz±0.1%

Output Voltage

220/230/240Vac,100V/110/120VAC

Input

Input Voltage

12 VDC

Input Voltage Range

10.0~15.0 VDC

Low Voltage Alarm

10VDC±0.2VDC

Low Voltage Shutdown

9.5VDC±0.2VDC

Over Voltage Alarm

15.5VDC

Standard Efficiency

87% (Full Loading)

Maximum Efficiency

90% (1/3 Loading)

No Loading Consumed Current

< 0.2A

Input Terminals

Cigar Plug Cable Included. (Input 12VDC only)

Output Terminals

Output Socket/Outlet

Working Temperature Range

 -10°C to +50°C

Working Humidity Range

20%~90% RH  Non-Condensing

Storage Temperature Range

 -30°C to +70°C

Pro Size (mm)

105*95*56 mm

Pro Weight (Kg)

0.75kg



 Plug seat
