2 Years Warranty 20w Led Waterproof Single Output Ac Dc Power Supply 15v

Name: 2 Years Warranty 20w Led Waterproof Single Output Ac Dc Power Supply 15v
Brand: weihao
SKU: 120488163
Availability: InStock

Zhejiang Weihao Electronic Co., Ltd.

US$ 3.9 - 5.6 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

weihao

Model Number:

LPV-20-15

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name weihao

Model Number LPV-20-15

Output Power 1 - 50W

Output Type Single

Input Voltage 220V

Output Voltage 15V

Output Frequency 47-63hz

Output Current 1.3A

20w Waterproof Single Output Ac Dc Power Supply 15vpaymnt term:30%deposit

ac dc power supply 15v
1.CE RoHS approved
2.2 years warranty
3.80% efficiency
4.High quality

ac dc power supply 15v ac dc power supply 15v

Model	LPV-20-12	LPV-20-24
DC output voltage	12V	24V
Output voltage error	1%	1%
Rated output current	1.5A	0.8A
Output current range	0-1.5A	0-0.8A
Wave and noise	80mVp-p	80mVp-p
Inlet stability	0.5%	0.5
Load stability	1%	0.5%
DC output power	20W	20W
Efficiency	83%	83%
AC input voltage range	170-264 VAC
Input current	0.5A/115V 0.25A/230V
AC impulse current	Cold-start current 13A/115V 26A/230V
Leakage current	<0.5mA/240VAC
Over load protection	105%~150% rated output power
	Protection:Hiccup mode
Over voltage protection	13~16V	28~32V
	Protection:Shut down output voltage
short circuit protection	Protection:Hiccup mode
Temperature coefficient	0.03%(050)
Setup rise hold up time	200ms,100ms,30ms
Vibration	10~500Hz,2G 10min./1cycle,Period for 60min,Each axes
Withstand voltage	I/P-O/P:2.5KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC
Isolation resistance	I/P-O/P:100M Ohms / 500VDC / 25 / 65% RH
Working temperature and humidity	-10~+60C, 20~90%RH
Store temperature and humidity	-20~+85C, 10~95%RH
Overall dimension	183×30×20mm
Weight	0.22Kgs
Safety standards	Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved
EMC	EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved
