Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply

Name: CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply
Brand: weihao
SKU: 120484801
Availability: InStock

Zhejiang Weihao Electronic Co., Ltd.

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-1

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-2

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-3

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-4

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-5

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply thumbnail-6

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-1

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-2

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-3

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-4

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-5

CE RoHS Approved S-100-12 12v 100w Ac/dc Switch Power Supply photo-6

US$ 6.5 - 8.8 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

weihao

Model Number:

S-100-12

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name weihao

Model Number S-100-12

Output Power Other, 100W

Output Type Single

Input Voltage Other, 110/220V

Output Voltage 12V

Output Frequency 47-63HZ

Output Current 8.5A

WEHO CE RoHS approved S-100-12 12v 100w ac/dc switch power supply

Model Specification	S-100-3	S-100-5		S-100-7.5		S-100-12	S-100-15	S-100-24	S-100-27	S-100-48
DC output voltage	3V	5V		7.5V		12V	15V	24V	24V	48V
Output voltage rang(Note:2)	+/-2%	+/-2%		+/-1%		+/-1%	+/-1%	+/-1%	+/-1%	+/-1%
Rated output current	50A	40A		29A		25.8A	23.2A	14.6A	13A	7.3A
Output current range	050A	040A		029A		025.8A	023.2A	014.6A	013A	07.3A
Wave and noise(Note:3)	150mVp-p	150mVp-p		150mVp-p		150mVp-p	150mVp-p	150mVp-p	200mVp-p	240mVp-p
Inlet stability(Note:4)	+/0.5%	+/0.5%		+/0.5%		+/0.5%	+/0.5%	+/0.5%	+/0.5%	+/0.5%
Load stability(Note:5)	+/1%	+/1%		+/1%		+/1%	+/1%	+/1%	+/1%	+/1%
DC output power	250W	300W		348W		348.3W	348W	351W	351W	350.4W
Efficiency	73%	76%		74%		79%	78%	82%	82%	83%
Adjustable range for DC voltage	4.5-5.6V	6-9V		10-13.2V		12-15V	13.5-18V	20-26.4V	26-32V	41-56V
AC input voltage range	85~132VAC/180~264VAC selectd by switch 47~63Hz; 255~370VDC
Input current	2.4A/115V 1.2A/230V
AC inrush current	Cole-start current 15A/115V 36A/230V
Leakage current	<1mA/240VAC
Overload proctection	105%~150%		150%~200%		105%~150%
	Type:pulsing hiccup shutdown Reset:auto recovery
Over-voltage proctection	105%~150%		150%~200%		105%~150%
	Type:pulsing hiccup shutdown Reset:auto recovery
High-temperature and protection	105%~150%		150%~200%		105%~150%
	Type:pulsing hiccup shutdown Reset:auto recovery
Temperature coefficient	+/-0.03%(0~50)
Setup, rise,hold up time	200ms,100ms,30ms
Vibration	10-500Hz,,2G10min,/cycle, periodfor 60min,Each axes
Withstand voltage	Input and output interal:1.5KvAC,Input ad enclosure:1.5KvAC Output and enclosure:0.5KvAC
Isolation resistance	Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ
Working temperature and humidity	-10+60(Refer to output derating curve),20%90%RH
Stoerall dimension	-20+85.10%~95%RH
Overall dimension	1999838mm
Weight	0.65Kgs
Safety standards	Meet UL1012 requirement(Not apply for the mark)
EMC standaras	Meet FCC PART 15J Conduction class B

Product Description

Packaging & Shipping

we use 4 trips to reinforce our carton,

the international standards package methods guaranteed our goods safety during transportation

we are a professional manufacturer of power supplies ,

all of our products have approved CE ROHS and ISO9001:2008

Our Services

Company Information

FAQ

1.Voltage

• Output XXV on the switching power supply. XX is the voltage.

E.g.: 5V, 9V, 12V, 13.8V, 15V, 18V, 24V, 36V 48V .............

2.Current:

• Output XXA on switching power supply . XX is the current.

E.g.: 0.5A , 1A, 1.5A, 2A, 3A, 4A, 5A, 6A 10A 15A 20A 30A 40A 50A 60A 80A ......

3.Quality

• We have the best professional and experienced engineer and strict QA and QC system. Rpair rate under 0.1%~0.2%.

4.Delivery

• Strong production capacity: 6000 pieces per day, could provide customerlized package upon request. We will make the the shipping to be the most economical for you and freight cost is informed in advance for your consideration and requirements

5. Guarantee period

• During the guarantee period, if any defect and/ or inherent fault is discovered, the Buyer shall notify the Seller and supply evidence of the defective,faulty parts or damaged goods,after seller's testing and confirmation,if commodity is damaged owing to defective products ,The Seller shall take prompt action to remedy, repair, or replace the defective or faulty parts at his own expenses within 07 days after receipt of Buyer’s notice by fax/mail.

6. Applications

• Power tools series: Electric Saw, Drilling Machine, Ginder, Sand blast Machine, Puching Machine,Weeding Machine,Air Compressor etc.

• Office series: Computer,Printer,LCD Monitor,Scanning Machine etc.

• Household Appliance series: Dust Collector,Fan Lamp or LED ,Sewing Machine etc.

• Kitchen Appliance series: Microwave Oven, Fridge, Freezr, Coffemarker etc.

• Industrial Equipemnt series: shipping,vehicle,metalhalide lamp,solar system,wind power generation ect.

• Electrical filed series: TV,VCRS,Radio ect.

7.Distributor

We are looking for distributor and agent all over the world for switching power supply . Should you any interest, please do feel free to send your message or inquiry. Welcome and join us, 24 hours service waiting for you. .Promt delivery and professional after-sales service are our priority ,which makes us to be your reliable partner.
