300mm PC housing Led Traffic Light-Led Arrow lamp

Specifications

1)Led traffic light
2)Low power consumption
3)Compatibility with most traffic housings and controllers
4)led arrow light





 Led traffic light/Led traffic lamp/Led traffic signal light



Features & Benefits

(1) Housing materialPolycarbonate

(2) DimensionΦ300mm,

(3) Luminous Intensity  Red and yellow 600cd,Green400cd

(4) Chromaticity

Red 625±5nm

Yellow 590±5nm

Green 505±2nm

(5) Power Supply AC220V/110V±20%  50Hz/60HZ

(6) Power ≤10W

(7) Power Factor ≥0.9

(8) Operation Temp. -40~+85

(9)Humidity ≤90%

(10)Life Time 50000h

(11)Weight ≤15kg

(12)Temperature Range:Class B

(13) Impact Resistance: Class    IR2

(14) Ingress:IP54



Model Number	Size (mm)	Color (nm)	Voltage (Typical)	Voltage Range	Power(w) Typical	Operation Temperature	Power(Hz) Frequency	Material
JXJ 300-3J/PL	300	R (625)   Y(590)   G (505)	220v 110V	95v-250v	10	-40°F~+80°F	50	Polycarbonate
