Specifications
1)Low power consumption2)Cast aluminium housing led traffic light
3)400 U-Turn traffic light
4)Led traffic light
1.Product Summary: | ||||||||||||||
DT400-3B traffic signal head use LEDS as light source. It consists of three-color U-turn lights with cast alluminium housing. Diameter of optical is Φ400mm. | ||||||||||||||
Feature: | ||||||||||||||
|
This light use pixelate design. The emitting surface is clean and beautiful. It is characterize with wide viewing angle, uniform brightness, standard chromaticity, low power consumption, long life time. | ||||||||||||||
2.Range of application: | ||||||||||||||
This light is applied for all necessary U-turn traffic road junctions. | ||||||||||||||
3.Product parameter: | ||||||||||||||
Description |
Model |
Drawing Number |
Dimension |
Housing Material |
Housing Color |
|||||||||
400 U-turn light |
DT400-3B |
DT400-3B/000.000.000 |
1582 X 650 X 472mm |
cast aluminium |
black |
|||||||||
| ||||||||||||||
Color |
Size of Emitting Surface |
Lens Feature |
LEDS |
LED Number |
Central Light Intensity |
Optical Feature |
Voltage |
Rated Power |
Standard |
|||||
red |
Φ400mm |
flat lens with scaly pattern |
Φ5(0.06W) |
283pcs |
>6000cd/m2 |
Pixelate design |
AC176 ~ 264V |
≤15W |
GB14887 -2003 |
|||||
yellow |
Φ400mm |
Φ5(0.06W) |
127pcs |
>6000cd/m2 |
≤15W |
|||||||||
green |
Φ400mm |
Φ5(0.06W) |
283pcs |
>6000cd/m2 |
≤15W |
|||||||||
4.Dimension: | ||||||||||||||
| ||||||||||||||
