White liquor Beer fruit juice industry diatomite filter
- 300 Set / Sets per Month
- Shanghai
- T/T
- Juice Filter Bag Filter Machine for Fruit Juice
- Industry automatic horizontal fruit juice filter and separating machine
- Newest professional automatic horizontal fruit juice filter machine
- Trade assurance good quality automatic industrial juice filter machine
- Hot sale large capacity industry using automatic fruit juice filter machine
- diatomaceous earth beer filter/disc filter
Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | RUNLAN |
Model Number: | WK500-38 | Processing Types: | Milk | Voltage: | 380V |
Power(W): | 3.5KW | Weight: | 1100KG | Dimension(L*W*H): | 2450x750x850 |
Certification: | CE,SGS,ISO9001 | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
White liquor Beer fruit juice industry diatomite filter specification:
plate and frame filter press
1.stainless steel ss304 or ss316
2.polished inside outside
3.application:dairy,beverage
This filter is with the introduction of international advanced technology, using 1Gr8Ni9Ti high grade stainless steel material and using diatomaceous filter media as filter aid. This machine make us stride forward from antiquated pulp filter process to advanced filter process .
It has some features such as good looks, easy operation, low cost filter, high efficiency, 99.8% clarity.
If you operate properly, it even can filter colibacillus. It is widely used in water treatment of white spirit, yellowwine, juice. We will do our best to help you to get good result in filter process.
White liquor Beer fruit juice industry diatomite filter advantages:
1.It can be used in all kinds of suspension liquid for separating solid and liquid, such as food, environmental protection, lightly industry, medicine, chemical industry, metallurgy, petroleum industry, etc.,
2.especially large quantity of liquid beverage precise filtration or degerming filtration in beer, white spirit, wine, oil.
Suspension liquid are sent by material pump into every sealed filtrating chamber. Under pressure, liquid goes through filtrating layers and filtrating cloth,
and then discharged from outlet but residue are kept in filtrating frame to separate solid and liquid
Main Technological Parameters:
Diameter(mm) | Number of frames | Pressure(Mpa) | Flow rate (T/h) | Motor(Kw) |
100 | 10 | 0.15 | 0.8 | 0.55 |
150 | 10 | 0.15 | 1.5 | 0.55 |
200 | 10 | 0.15 | 2.0 | 0.55 |
300 | 10 | 0.2 | 4.0 | 1.10 |
400 | 10 | 0.2 | 6.0 | 1.10 |
400 | 16 | 0.3 | 9.0 | 1.50 |
400 | 20 | 0.3 | 10 | 1.50 |
400 | 24 | 0.3 | 12 | 2.20 |
400 | 32 | 0.3 | 14 | 2.20 |
Our Service/ company:
Shanghai Runlan filtration equipment Co., Ltd. is a professional engaged in research, design , manufacture and sales of filtration equipment for the integration of Science & Technology entities of private joint-stock enterprise which founded in 2008. Registered capital of 3 million , 120 employees , annual turnover ( RMB ) 50 million. 2010 successfully registered "Run –Lan " trademark has become well-known brand in the industry.
Our Company:
Products Display:
Our Certificate:
Locale Experimentation:
Exhibition:
Support OEM
We are professional manufacturer of filtration equipment in China mainland with the standard and the non-standard products for any field.Such as Electronic components & Supplies Pharmaceuticals industry and so on.Everything will be refer to the customers' needs .
Factory Tour
Our factory are professional for the filter for several years , we have 120 staff now .and many of them have above 5years experience , with 3production lines and our continuous effort ,innovation ,we have got many good reputation From our customers . We are of confidence to create a great future !
Team Show
Packing and Shipping
Service Display
Customer Photo
FAQ
1 | Are you manufacturer? |
Yes, we are manufacturer , our factory is located in Shanghai,China. Welcome your coming to visit us! | |
2 | What's your MOQ? |
One piece sample is ok and more quantities, more favorable price | |
3 | Do you accept OEM? |
Yes, we can manufacture according to your requirement | |
4 | What is the process to place an order ? |
At first, you tell me which styles of products ( From our website or Send us your product's photos or the artwork ) you will need ? Second, If you need , we will provide you the details too ,as the technical parameters or the artwork for your approval . Third, After ensure the more details about the products ,we will quote you about it ,and if you accept ,PI will would like goes for you . Fourth, You need to make full payment or take 30% payment before production and 70% before shipping . | |
5 | Are customized products accepted? |
We are support any of your innovative idea and also will provide you the filtering scheme for your reference . Runlan is your factory ! | |
6 | Any discount possible if I place an order? |
Yes. we have different price ranges (discounts) based on different order quantities. Please contact our sales for detailed price information. | |
7 | How long is the delivery time ? |
Different products and quantities have different procedures and different timing .We may promise that we can try our best to finish all of your orders within the shortest time. For more information, please contact us directly | |
8 | More information about the payment terms ? |
We accept the TT , West Union and Cash . | |
9 | How to realize continuous filter for the bag filters? When to exchange the filter bag ? |
A. The bag filter can be fixed in parallel and exchange the filter bag , so guarantee it can filter continuously . B. (a) refer to the experiences to make rough estimation for it . (B) Fix the pressure gage , once the differential pressure reach the section as 0.5-1kg/cm2,we will need to exchange the filter bag . | |
10 | How is the quality of the filters? |
At Sinft we insist on providing our customers with the highest quality of filtration products. As a result, all of our replacement elements are manufactured right here in China, under the most rigorous quality standards. Additionally, all of our filter elements carry six ISO Standards and we fully guarantee all of our products. |
