"Explosive Proof Cable GlandsAccessories"
Brass Cable Glands Accessories :
| Brass Locknuts |
| Application | Brass Locknuts re traditional components used in fastening glands to the gland plate & as they are identical material to the gland, corrosion effects are minimal. |
| Function | With ISO metric thread. To secure only brass cable glands to a gland plate |
| EMC | With ISO metric thread with cutting edges to cut through paint layers or powder coatings, for optimum contact. |
| Matrial | Brass BS 2874 CZ121 Pb3 |
| Thread | ET NPT BSP BSPT PG |
| Plating | Chrome (CP) Nickel (NP) Tin (TP) |
| Brass Earth Tag |
| Application | Installed between the gland entry & equipment, provides an earth bond connection |
| Function | Produces an earth bond connection for electrical continuity |
| Material | Brass BS 2870 CZ123 lead |
| Type | With Brass Screws & Washers, Plain Hole |
| Plating | Nickel (NP) Chrome (CP) Zinc (ZP) Tin (TP) |
| Shape | Available in many shapes & thickness in all sizes, can be coated or plated to customers specification as mentioned. |
| Hexagonal Reducers & Stop Plugs |
| Application | Reducer allows a PG threaded gland to be terminated in enclosures with different entry thread form (ET NPT BSP BSPT) |
| Function | Reduce the entry thread diameter of enclosures |
| Material | Brass BS 2874 CZ121 Pb3 |
| Finish | Electro Nickel Plated |
| Thread | Metric (ISO) ET NPT BSP BSPT |
| Plating | Chrome (CP) Zinc (ZP) Tin (TP) |
| Application | Stop Plug may be used to close thread entries or means of sealing & stopping unused thread entries in flame proof enclosures |
| Ingress Protection | IP66 (with Nickel Thread Seal) IP368 (3 bar-with Nitrite 'O' Rings) |
| Options Thread | ET NPT BSP BSPT & PG |
| PVS Shrouds |
| Application | Push on shrouds which are used to minimize the risk of dirt or foreign substances gathering on the Cable Gland Body, and/or point of cable to a gland interface. |
| Function | For all types of gland applications to provide additional protection & enhances the IP rating of the gland termination. |
| Material | PVC DIP moulded (Black) |
| Operating Temp | PVC DIP moulded -200 C to +1000 C |
| Injection moulded -200 C to +800 C |
| Star Washers |
| Application | The serrated lock washer with external teeth for cable glands |
| Material | Brass |
| Size | From M 20 to M 63 |
| Seals & 'O' Rings |
| Application | To maintain the IP rating between equipment & cable glands it may be necessary to fit an entry thread sealing washer at the gland entry interface. |
| Material | Nitrite Rubber & EPDM |
| Options Material | PVC (Black) Silicon (Orange) Polyamide or Nylon (White) Red Fibre. |
| Special Feature | Seals available for both external of & internal use. |
"Customer's satisfaction is first priority for us"
Since 1981, CanaryBrass are Brass Parts Products Suppliers Company in India. Our aim is supplying high quality material for the growing demand in chemical industries, pharmaceutical etc. Our Expert Engineers Made Quality Brass Products. We have a large number of distributors spread across the world. We already exported in US, UK, Germany etc. Our expert service is clients satisfied. Because we believe in business in a relationship.
We Manufacturing different type of Brass products like Banana Plug, Brass Anchors, Brass Auto Parts, cable glands, Cut Out Terminal, electrical connectors, HRC Contact Block, Neutral link, PCB terminal, RF Connectors, sanitary fittings, Terminal block etc.
