RHZA-A Series Candle Filter
US$ 1,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Medium Material:
Other
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale Small Yellow Wine FilterUS$ 1,000 - 30,000MOQ: 1 Set -
China Manufacture Candle Filter IndustryUS$ 1 - 10,000MOQ: 1 Set
-
RHZS-C Series Candle FilterUS$ 1,000 - 100,000MOQ: 1 Set
-
RHZS -A Series Chemical Industry Candle Filter for FoodUS$ 4000.00 - 4000.00MOQ: 1 Set
-
Chemical Industry Candle Filter for FoodUS$ 4000.00 - 4000.00MOQ: 1 Set
Condition
New
Medium Material
Other
Place of Origin
Shanghai, China
Brand Name
Runlan
Model Number
RHZS
Dimension(L*W*H)
Customer Demand
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
The filtration, adsorption and solid recovery of metal catalyzer, zeolite etc, in the industries of fine chemical, plastic, fuel, electricity, grease, lubricant, porcelain, glass, alkali etc.
ZX Series Self-Clean Filtering Core Filter is a kind of clarifying separation equipment with high-efficiency, energy-saving and enclosed operation. It has traits as follows:
1.Completely enclosed filtration, no leakage, no pollution,
2.The filtering core adopts component structure which can be used widely and excellent filtering effect.
3.It can achieve thoroughly filtration one time.
4.Filter cake can be washed and dried and it can achieve the best economical benefit.
5.Adopting air blowing in reverse to discharge the residue which is rapid and clean, and also used in various sticky materials.
6.The whole process can achieve completely full-Automatization.
Working Principle
Normal filtering after a period of time, when the filter cake on the multihole filter cartridges reaches a certain thickness, will provide a singal control then the feed , then emptying the residual liquid which inside the filter, after that peovides a singal control the blowback port (compressed air, nitrogen or saturated steam) to process blowing back, make the cake fall off, after a certain time, stop blowing, provides a singal to open the port for discharge, after discharge close the discharge port, back to the initial state before filtering , ready for the next round of filtering .
Candle filter (also called microporous filter) in a closed container, combine by many pieces microporous filter cartridges, (or cover clothes outside the filter cartridges and filter medium), when filtering we should send the slurry into the filter with the pump, the liquid of the slurry through the filter medium into the center of the multihole filter cartridges, then collect them to discharge from the outlet port of the clear liquid. Before the information of the candle filter, the discharge " clear liquid" return to the raw material slurry inlet port then resend to filter as cycle filtering , until the candle filter formed ( can meet the filter requirements) , provides a singal and the control solution no longer cycle, clear liquid through the three-port valve to the use of next working procedure, then for normal filtering.
Our Company
Shanghai Runlan Filtration Equipment Co,. Ltd is a professional engaged in research, design, manufacture and sales of filtration equipment for the integration of Science &Technology entities of private joint-stock enterprise which founded in 2008.
Enterprises leading products are: bag filter, cartridge filter precision filter, candle filter, antomatic filter, filter press, diatomaceous earth filter, centrifuges, and other filtration equipment.
Leading Products
Packing & Delivery
FAQ
Q: Do you accept OEM?
Yes. We can manufacure according to your requirement.
Q: Are you a manufacturer?
Yes. We are a factory. And our factory is located in Shanghai, China.
Q:What your MOQ?
One piede sample is OK. More quantities, more favorite price.
Q:How long is the delivery time?
Different products and quantities have different procedures .We may try our best to finish all of your orders within the shortest time.
Q:More information about the payment terms?
We accept TT, Western Union, and Cash.
