RHZS -A Series Chemical Industry Candle Filter for Food

RHZS -A Series Chemical Industry Candle Filter for Food photo-1
RHZS -A Series Chemical Industry Candle Filter for Food photo-2
RHZS -A Series Chemical Industry Candle Filter for Food photo-3
US$ 4000.00 - 4000.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Medium Material:
Other
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Medium Material Other
Place of Origin Shanghai, China
Brand Name Shsnghai Runlan
Model Number Customized, RHZS-A-3
Certification CE, CB, CSA, ETL, RoHS, UL, UR
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Product Overview
The filtration, adsorption and solid recovery of metal catalyzer, zeolite etc, in the industries of fine chemical, plastic, fuel, electricity, grease, lubricant, porcelain, glass, alkali etc.
ZX Series Self-Clean Filtering Core Filter is a kind of clarifying separation equipment with high-efficiency, energy-saving and enclosed operation. It has traits as follows:
1.Completely ebclosed filtration, no leakage, no pollution.
2.The filtering core adopts component structure which can be uses widely and excellent filtering effect.
3.It can achieve thoroughly filtration one time.
4.Filter cake can be washed and dried and it can achieve the best economical benefit.
5.Adopting air blowing in reverse to discharge the residue which is rapid and clean, and also used in various sticky materials.
6.The whole process can achieve completely full-Automatization.
Working Principle

  Normal filtering after a period of time, when the filter cake on the multihole filter cartridges reaches a certain thickness, will provide a signal control then the feed (stop), then emptying the residual liquid which inside the filter, after that provides a signal control the blowback port(compressed air, nitrogen or saturated steam) to process blowing back, make the cake fall off, after a certain time, stop blowing, provides a signal to open the port for discharge, after discharge close the discharge port, back to the initial state before filtering, ready for the next round of filtering.

Technical Data
Model
RHZS-A-3
RHZS-A-5
RHZS-A-8
RHZS-A-10
RHZS-A-15
RHZS-A-20
RHZS-A-30
RHZS-A-40
RHZS-A-60
Material
SUS304&316L / Q235 / PIFE / rubber / linerPO
Filtration Area
3
5
8
10
15
20
30
40
60
Working Pressure
≦0.25Mpa
Working Temperature
≦80-110℃
Cake Volume
0.06
0.1
0.16
0.2
0.3
0.4
0.6
0.8
1.2
Body Diameter
600
800
1000
1200
1400
1600
1600
1600
2000
Caliber
DN25
DN32
DN40
DN40
DN50
DN65
DN65
DN65
DN65
Processing Capacity
 based on experimental data
Slagging Caliber
DN300
Product Details Show
About Our Company
Product Display
Packing and Shiping
FAQ

1.Are you manufacturer?

    Yes, we are manufacturer , our factory is located in Shanghai,China. Welcome your coming to visit us!


2.What's your MOQ?

    One piece sample is ok and more quantities, more favorable price.


3.Do you accept OEM?

    Yes, we can manufacture according to your requirement.


4.What is the process to place an order ?

    At first, you tell me which styles of products ( From our website or Send us your product's photos or the artwork ) you will need ? Second, If you need , we will provide you the details too ,as the technical parameters or the artwork for your approval . Third, After ensure the more details about the products ,we will quote you about it ,and if you accept ,PI will would like goes for you . Fourth, You need to make full payment or take 30% payment before production and 70% before shipping .


5.Are customized products accepted?

     We are support any of your innovative idea and also will provide you the filtering scheme for your reference . Runlan is your factory !


6.Any discount possible if I place an order?

     Yes. we have different price ranges (discounts) based on different order quantities. Please contact our sales for detailed price information.


7.How long is the delivery time ?

     Different products and quantities have different procedures and different timing .We may promise that we can try our best to finish all of your orders within the shortest time. For more information, please contact us directly
