Home > Products > Packing machines > Potato chips automatic packing machinery
Potato chips automatic packing machinery
- 20 Set / Sets per Month
- Qingdao
- T/T
You May Like
Product Details
| Condition | New | Application | Food, Medical, Other, Food, Medical, Machinery & Hardware, package fragile materials demanding high accuracy | |
| Packaging Type | Bags, Film | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V | Power | 2.2kw | |
| Place of Origin | Shandong, China | Brand Name | LT | |
| Model Number | LT420,LT520,LT720 | Dimension(L*W*H) | 1530x970x1600mm | |
| Weight | 450kg | Certification | CE ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1. Automatic chips packaging machine2. 10 heads combination weigher
3. Z type bucket elevator
4. Platform
5. Conveyor
1.Automatic potato chips packing machine
Puffed snacks packing machinery
Automatic vertical packing line
Vertical pistachio nuts packing line
Inflated snacks packing equipment
Chocolate chips packing machine
1). Automatic Snacks packaging machine
2). 10 heads combination weigher
3). Z type bucket elevator
4). Vibration feeder
5). Supporting platform
6). Finished product conveyor
2.Features
1). It automatically complete conveying product, measuring, bag-forming, filling, blowing nitrogen, date and code printing, cutting, finished product delivery
2). Famous brand PLC control system, wide version touch screen, convenient to operate. Film drawing down system and horizontal sealing controlled by servo motor; Multi-head balance can well assure the accurate weight of each package
3). Various package sizes can be made; Nitrogen filling device can be added.
4). Packing material: any laminated film such as POPP/CPP, POPP/VMCPP, BOPP/PE, PET/AL/PE, NY/PE, PET/PET, etc.
3. Technical Parameters
Model |
| LT-420 | LT-520 | LT-720 |
Capacity |
| Max 70bags/min | Max 60bags/min | Max 30bags/min |
Bag size |
| Width:60-200mm | Width:100-250mm | Width:150-350mm |
| Length:60-300mm | Length:80-350mm | Length:100-450mm | |
Max film width |
| Max 420mm | Max 520mm | Max 720mm |
Film thickness |
| 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm |
Power source |
| 2.2KW 220V 50HZ | 3KW 220V 50HZ | 4KW 220V 50HZ |
Air consumption |
| 0.8Mpa 0.5m3/min | 0.8Mpa 0.6m3/min | 0.9Mpa 0.7m3/min |
Dimension |
| L1400 x W970 x H1600 mm | L1430 x W1200 x H1700 mm | L1780 x W1350 x H2000 mm |
Weight |
| 450kg | 650kg | 800kg |
4.Sample
5.Delivery
6.Service & Installation
1).Consultation service before, during, and after sales;
2).Project planning and design services;
3). Debugging of equipment until everything is functional;
4). Management of equipments' long distance shipping from seller's factory to named place by buyer;
5).Training of equipment maintenance and operating personally;
6). New production techniques and formulas;
7). Provide 1 year complete warranty and life-time maintenance service.
