Specifications
1. Automatic packaging machine2. 10/14heads combination weigher
3. Z type bucket elevator
4. Platform
5. Conveyor
1.Automatic stand up pouch snacks packing machine
Full automatic vertical packaging machinery
Stand up bags/pouch automatic packaging line
Doypack pouch automatic packaging machinery
Puffy food Doypack pouch automatic packaging line
1). Automatic vertical packaging machine
2). 10/14 heads combination weigher
3). Z type bucket elevator with vibration feeder
4). Supporting platform
5). Finished product conveyor
2.Features
1). It complete conveying product, measuring, bag-forming, filling, blowing nitrogen, date and code printing, cutting, finished product delivery automatically.
2). Famous brand PLC control system, wide version touch screen, convenient to operate. Film drawing down system and horizontal sealing controlled by servo motor; Multi-head balance can well assure the accurate weight of each package
3) High precision, high efficiency without crash the materials
4). various package sizes can be made; Nitrogen filling device can be added.
5). packing material: any laminated film such as POPP/CPP, POPP/VMCPP, BOPP/PE, PET/AL/PE, NY/PE, PET/PET, etc.
3. Technical Parameters
Model |
LT-520 |
LT-720 |
Capacity |
Max 50bags/min |
Max 30bags/min |
Front width |
100-180mm |
100-240mm |
Side width |
50-90mm |
65-120mm |
Width of side seal |
5-10mm |
5-10mm |
Bag length |
100-350mm |
100-420mm |
Max film width |
Max 520mm |
Max 680mm |
Film thickness |
0.04-0.09mm |
0.04-0.09mm |
Power source |
3.5KW 220V 50HZ |
4KW 220V 50HZ |
Air consumption |
0.8Mpa 0.6m3/min |
0.9Mpa 0.7m3/min |
Dimension |
1600*1400*2000mm |
1700*1420*2100mm |
Weight |
750kg |
900kg |
4.Sample
5.Delivery
6.Service & Installation
1).Consultation service before, during, and after sales;
2).Project planning and design services;
3). Debugging of equipment until everything is functional;
4). Management of equipments' long distance shipping from seller's factory to named place by buyer;
5).Training of equipment maintenance and operating personally;
6). New production techniques and formulas;
7). Provide 1 year complete warranty and life-time maintenance service.
