Home Solar Inverter System 800W

Name: Home Solar Inverter System 800W
Brand: SAKO
Price: USD $250 - 600 / Piece

FOB Price

USD $250 - $600 / Piece

500 Pieces(Min.Order)

Supply Ability 20000 Set / Sets per Month
Port Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	SAKO	Model Number:	SLZ500-1000VA
Input Voltage:	110-270 or 75-125	Output Voltage:	220V or 100V+/-10%	Output Power:	400W,800W
Output Frequency:	50-60	Output Current:	3.6

Product Description

SAKO SLZ SERIES TECHNICAL PARAMETER

MODEL

SLZ-500VA

SLZ-1000VA

SPECIFICATION

AC BYPASS (IN AC MODEL)

Input AC Voltage (VAC)

220VAC or 100VAC

Input AC Range (VAC)

110-270VAC or 75 -125VAC

Input Frequency Range (Hz)

Same As Input Frequency

Input Current (A)

3.63A

7.27A

Charge Current (A)

8-12A

Transfer Time (ms)

UPS Setting :<= 4ms / Generator :<= 1s

Output Voltage (VAC)

220VAC or 100VAC ± 10%

BATTERY

Battery Built Inside

12V/100AH

12V/100AH*2

Battery Type

Maintainess Free Lead Acid Battery

Over Charge Protected Voltage (VDC)

14.5V±0.2V

29V±0.2V

Over Charge Back Voltage (VDC)

13.2V

26.4V±0.2V

Over Discharge Protected Voltage

10.5V±0.4V

21V±0.2V

OUTPUT (IN BATTERY MODEL)

Output Power (W)

400

800

Output Voltage (VAC)

AC 220V/100V±3% (In Battery Model)

Output Frequency (Hz)

60/50Hz±1% Auto Sense (In Battery Model)

Output Wave Form

Pure Sine Wave

Wave Distortion (TCKJ)

<= 5%

Back Up Time (Full Load)

>10 Hours (36W AC Lamp or 50W AC FAN)

>10 Hours (One PC)

Overload & Shortage Protection

Yes

Output Overload Capacity

100%~120%,25S; 120%~200%,1S; >200%,0.1S

By Pass Transfer Time

<= 4ms

PROTECTION

Protection

Over temperature/ over load/ over voltage/ low battery/ low voltage/ Input low/ hight voltage/ short current Protection

AMBIENT

Noise (dB)

< 50dB (1 Meter)

Working Temperature

-20°C to 50°C

Humidity

0~95% (No Condensation)

Sea Level (m)

<=1500m

DIMENSION

L×W×H (Products Size) (mm)

500*200*538 mm

510*372.5*460 mm

L×W×H (Package Size) (mm)

597*290*669 mm

587*472*600 mm

Weight (N.W. KG)

48 KG

91.5 KG

Weight (G.W. KG)

50.5 KG

110.5 KG

20Ft Qty (Unit)

220

160
