Home > Electrical & Electronics > Inverter > Power Inverter > Pure Sine Wave Inverter Pure Sine Wave Lnverter 1- 6KW/12V or 24V or 48V
Pure Sine Wave Inverter Pure Sine Wave Lnverter 1- 6KW/12V or 24V or 48V
US$ 100 - 500
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SKN-S 1-6KW
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hybrid Solar Inverter SKN-SC 6000W 220V With Big LCD and Solar Charge Controller MPPT 50AUS$ 149.9 - 999.9MOQ: 100 Pieces -
SAKO Solar Inverter With Big Charger JMS 5000 220V MPPT 50AUS$ 149.9 - 999.9MOQ: 100 Pieces
-
SAKO Solar Air Conditioning Inverter for 1Hp,1.5Hp,2Hp Air Conditioner Directly by Solar Power With Backup UsageUS$ 200 - 3,000MOQ: 10 Units
-
Sine Wave Solar Inverter SKN-MDS 500VA To 3000VAUS$ 79.9 - 359.9MOQ: 1000 Pieces
-
2016 Double Use Home Inverter Solar Inverter With Modify Sine Wave SKN-H 600W 1200W 2000WUS$ 35 - 85MOQ: 200 Units
Place of Origin
Guangdong, China
Brand Name
SAKO
Model Number
SKN-S 1-6KW
Output Power
Other, >1000W
Output Type
Single
Size
438*184*181mm
Weight
1000VA:16.5kgs
Input Voltage
110V or 220V
Output Voltage
110V or 220V
Type
DC/AC Inverters
Output Frequency
50/60Hz
Output Current
5-30A
| |||||||||||||
| MODEL | SKN-S 1KW | SKN-S 2KW | SKN-S 3KW | SKN-S 4KW | SKN-S 5KW | SKN-S 6KW | |||||||
| SPECIFICATION | |||||||||||||
| DC INPUT | |||||||||||||
| Input Voltage (VDC) | 12V/24V/48V | 24V/48V | |||||||||||
| Min DC Start Voltage (VDC) | 10V/20V | 20V/40V | |||||||||||
| AC BYPASS | |||||||||||||
| Nominal Input Voltage (VAC) | 110VAC or 230VAC | 230VAC | |||||||||||
| Input AC Range (VAC) | 110VAC:80~140VAC or 220VAC:165~265VAC (Wide) / 185~265VAC (Narrow) or 90~265VAC (1~3KW) | 165~265VAC (Wide), 185~265VAC (Narrow) | |||||||||||
| Frequency Range (Hz) | 50Hz or 60Hz (47Hz~53Hz for 50Hz)-(57Hz~63Hz for 60Hz) | ||||||||||||
| Input Frequency (Hz) | 50Hz/60Hz (Auto Detection) | ||||||||||||
| Bypass Output Voltage (VAC) | Same As Input Voltage | ||||||||||||
| Bypass Output Frequency (Hz) | Same As Input Frequency | ||||||||||||
| Pass Through Without Battery | Yes | ||||||||||||
| Max Bypass Overload Current (A) | 10A | 30A | 40A | ||||||||||
| AC Efficiency | > 95% | ||||||||||||
| Transfer Time (ms) | 20ms (Typical) | ||||||||||||
| CHARGER | |||||||||||||
| Charge Mode Input Voltage Range |
85~135VAC or 175~255VAC (Wide) / 195~255VAC (Narrow) | 175~255VAC (Wide) / 195-255VAC (Narrow) | |||||||||||
| Automatic Charge Mode | Three Stage Charge Mode:Boost CC (Constant Current Stage) → Boost CV (Constant Voltage Stage) → Float (Constant Voltage Stage) | ||||||||||||
| Nominal Charge Voltage | According To The Battery Type Setup | ||||||||||||
| Charge Current (A) | 70A (Maximum) | ||||||||||||
| Charge Boost Voltage (VDC) | According To The Battery Type Setup (12V BAT:14-15.5V 24V BAT:28-31V 48V BAT:56-62V 96V BAT:112-124V) | ||||||||||||
| Charge Floating Voltage (VDC) | According To The Battery Type Setup (12V BAT:13.3-13.7V 24V BAT: 26.6-27.6V 48V BAT:53.2-55.2V 96V BAT:106.4-110.4V) | ||||||||||||
| Over Charge Protection | Bat.V ≥ 15.7VDC,Beeps 0.5s Every 1s & Fault After 60s (15.7V for 12V, 31.4V for 24V, 62.8V for 48V, 125.6V for 96V) | ||||||||||||
| Charger Short Circuit Protection | Circuit Breaker | ||||||||||||
| INVERTER | |||||||||||||
| Capacity (VA) | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | |||||||
| Output Power (W) | 1000 | 2000 | 3000 | 4000 | 5000 | 6000 | |||||||
| Power Factor (PF) | 1 | ||||||||||||
| Output Voltage (VAC) | 120VAC or 230VAC (Pure Sine Wave) | 230VAC (Pure Sine Wave) | |||||||||||
| Output Frequency (Hz) | 50/60 ± 0.3Hz (Auto Tracking Main First Power Connection) | ||||||||||||
| Wave From | Pure Sine Wave | ||||||||||||
| Inversion Efficiency | > 88% | ||||||||||||
| Over Load Capacity | (110%<Load<125%)±10%: Fault (Shutdown Output) After 15 Minutes || (125%<Load<150%) ±10%: Fault (Shutdown Output) After 60S || Load>150% ±10%: Fault (Shutdown Output) After 20S | ||||||||||||
| Low Battery Alarm | 10.5VDC±0.3VDC for 12V Battery, 21.0VDC±0.6VDC for 24V Battery, 42.0VDC±1.2VDC for 48V Battery, 84.0VDC±2.4VDC for 96V Battery | ||||||||||||
| Power Saver | Load ≤ 25W (Enabled On “P/S Auto” Setting Of Remote Control) | ||||||||||||
| AMBIENT | |||||||||||||
| Noise (dB) | 60dB Max. | ||||||||||||
| Temperature | 0°C to 40°C | ||||||||||||
| Humidity | 5% to 95% | ||||||||||||
| Sea Level (m) | ≤ 1500m | ||||||||||||
| DIMENSION | |||||||||||||
| Product Size L×W×H (mm) | L438mm*W184mm*H181 mm | L608mm*W184mm*H181 mm | |||||||||||
| Packing Size L×W×H (mm) | L590mm*W312mm*H295 mm | L808mm*W360mm*H352 mm | |||||||||||
| Weight (KG) | 16.5/17.5KG | 19/20KG | 24/25KG | 34/37KG | 38.5/41.5KG | 44.5/47.5KG | |||||||
| | |||||||||||||
