Solar Inverter SKN-HDS Series Solar System With and Controller and Wide Input Voltage
US$ 100 - 1,000
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SKN-HDS
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SKN-HDS Hy-brid Solar System With and Controller and Wide Input VoltageUS$ 100 - 1,000MOQ: 10 Sets -
Solar Inverter SKN-SS 3KW/48V With Big Charge CurrentUS$ 149.9 - 999.9MOQ: 100 Pieces
-
Sine Wave Solar Inverter SKN-MDS 500VA To 3000VA 2015 Newest InverterUS$ 79.9 - 359.9MOQ: 1000 Pieces
-
Inverter SKN-SS 2KW/12V/24V With Solar Charge ControllerUS$ 149.9 - 999.9MOQ: 100 Pieces
-
Off Grid Solar Inverter SKN-SS 2KW/12V/24V With Big Solar Charge ControllerUS$ 149.9 - 999.9MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
SAKO
Model Number
SKN-HDS
Specification
Normal
Application
Home
Output Voltage (V)
220V
Load Power (W)
300W-1200W
Solar Power (W)
100W-3000W
Work Time (h)
as long as it works
| MODEL | SKN-HDS600 | SKN-HDS1000 | SKN-HDS2000 |
| SPECIFICATION | |||
| Load capacity | 3light + 3FAN | 5Light+5Fan | 10light+10fan |
| Leading time | within 30 days for 1*20 FT container | ||
| DC INPUT | |||
| Input Voltage(Vdc) | 12 | 12 | 24 |
| Input DC Range(Vdc) | 10~15 | 20~30 | |
| AC Bypass in “on/off” switch off mode | |||
| Input AC Range(Vac) | 220/230/240VAC | ||
| 177-280V(Narrow Range) or 90-280VAC (Wide Range) | |||
| Input Frequency(Hz) | 50/60 HZ | ||
| Bypass Output Voltage(Vac) | SAME AS INPUT AC | ||
| Bypass Output Frequency(Hz) | SAME AS INPUT Frequency | ||
| Charge Current(A) | 10A±2A or 10A- 20A Selectable | ||
| Charge Floating Voltage(V) | 13.75±0.2V | 27.5±0.4V | |
| Over Charge Voltage(V) | 15.0V±0.4V Charge stop | 30.0V±0.8V Charge stop | |
| AC Efficiency | > 97% | ||
| Transfer Time(ms) | Typical 15ms | ||
| Solar Controller | |||
| Solar controller | 10A 12V | 20A 12V | 30A 24V |
| AC OUTPUT (INVERTER) | |||
| Capacity(VA) | 600 | 1000 | 2000 |
| Output Power(W) | 360 | 600 | 1200 |
| Output Voltage | 220VAC | ||
| Output Frequency | 50/60HZ | ||
| Output Current(A) | 2.7/1.6 | 4.5/2.7 | 9.1/5.5 |
| Voltage Precision(VAC) | 220±10% | ||
| Frequency Precision(HZ) | 50/60Hz±0.1HZ | ||
| Wave | modify sine wave | ||
| Power Factor(PF) | 0.6 | ||
| Inversion Efficiency | >85% | ||
| Bypass Transfer time(ms) | <=8 ms | ||
| Over load capacity | over load 110%,60s later shut offer | ||
| PROTECTION | |||
| Protection | over load/ short circuit protection | ||
| Over charge , discharge protection | |||
| AMBIENT | |||
| Noise(dB) | <=40 (1 mter) | ||
| Temperature | -20~45 degree | ||
| Humidity | 0~95% ( no condensation) | ||
| Sea Level(m) | <=1500 | ||
| DIMENSION | |||
| Package L×W×H(mm) | 638*370*552mm( 10pcs in one carton) | ||
| GW. Weight(Kg) /Carton | 26.5 | 27.5 | 28.2 |
