refiner reclaim rubber machine / scrap rubber refiner used tire reclaimed
- 100 Set / Sets per Month
- Qingdao Port
- T/T
Product Details
Condition: | New | Type: | Other, Rubber Refining Mill | Place of Origin: | Shandong, China |
Brand Name: | Qingdao Junlin | Model Number: | as per order | Voltage: | as per order |
Power(W): | as per order | Dimension(L*W*H): | as per order | Weight: | as per order |
Certification: | CE ISO SES | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
refiner reclaim rubber machine / scrap rubber refiner used tire reclaimed
1. Introduction of Rubber Refining Mill
The rubber refiner is mainly used for refining of reclaimed rubber and rubber sheeting. The rollers are made of chilled cast iron with wear-resistant hard surfaces. The two rollers are smooth ones with bored cavities and can be cooled homogeneously. The protective device is provided to protect the main parts from damage due to overload. In case of emergency, the safety rod is pulled down and the rollers will be stopped immediately.
2.Features of Rubber Refining Mill
1'Two rollers are made from Chilled Cast Iron, smooth surface is highly polished and scratch proof by cutting knife: high hardness and wear-resistant;
2'The roller is hollow structure, which is for adjusting the temperature of the rollers by steam or cooling water in term of different request;
3'The machine is equipped with an overload protection device to prevent the major components from being damaged due to overloading.
4'The machine is also equipped with an emergency device. When an emergent accident happens, just draw the safety pull-rod, and the machine will stop immediately. It is safe and reliable.
5'The machine is equipped with scraper and wind-up unit, which can take the reclaimed rubber away from the wind-up roller
3.Main Technical Parameters of Rubber Refining Mill
Technical parameter Type | XKP-400 | XKP-450 | XKP-560 | XKJ-400 | XKJ-480 |
Front roll diameter(mm) | 400 | 450 | 560 | 400(Waist-drum) | 480(Waist-drum) |
Rear roll diameter(mm) | 400(Groove roller) | 450(Groove roller) | 510(Groove roller) | 518(Waist-drum) | 612(Waist-drum) |
Working length of rolls | 600 | 650 | 800 | 760 | 800 |
Front roll surface speed | 17.32 | 23.2 | 25.56 | 25 | 26.6 |
Friction ratio | 1:1.38 | 1:1.38 | 1:1.30 | 1:1.707 | 1:1.75 |
Max.nip(mm) | 8 | 8 | 15 | 10 | 15 |
Motor power (kw) | 45 | 55 | 75 | 45 | 75 |
Overall dimension :Length×Width×Height | 3950×1800 | 4770×1846 | 5064×2284 | 4770×2300 | 5070×2800 |
4.Picture of Rubber Refining Mill
5.Our service
1.One year guarantee for whole machines
2.24 hours technical support by email
3.Calling or door - to -door service
4.Provide videos for each machine
5.We will send one engineer to your factory to guide installation and test running the production line, until you can operate the machine skilled
6.Our workshop and factory
7.Our certificate
CE ISO9001 SGS
Welcome to send inquiry and visit us to check the quality!
