Large capacity high efficiency grizzly feeder machine

Name: Large capacity high efficiency grizzly feeder machine
Brand: DAHAN
Availability: InStock

FOB Price

USD $800 - $10,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port Any port of China(Mainland)
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Mining Industry
Power Type	Electric	Capacity(t/h)	200-350t/h
Place of Origin	Henan, China	Brand Name	DAHAN
Model Number	BTZS	Power(W)	18.5-30kw
Dimension(LWH)	as per model	Weight	as per model
Certification	ISO9001:2008	Warranty	12 Months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

About product

1.Description of ore grizzly feeder conveyor machine

The structure is with the connection of groove rivet in the shape of frame. Shield and bars are made of manganese steel. Furthermore,the top-quality vibrator and the hard structure can stand the high-strength assault and wore. Apply to the conveying of big size lump material to the crusher. Especially for the material like, back ore, nonferrous metal ore and stone for building. During the feeding, the un-necessary material like earth and small size particle can be separated under the gap between the bars,thereby, making the crusher be with a better performance.

2.Features

l Feeder for crusher.

l Long time service life.

l Strong structure, stable operation.

l Large output.

l Stand the high-stregth assault and wore.

3.Application Range:

l Size classification: separation of particles into groups of comparable size from the materials.

l Gravity filtering: removal of solids from liquids and slurries.

l Product reclamation: removal of the solids from waste product or clarification of waste liquor for further use.

l Screening: separation of a few oversize particles from a quantity of materials.

l Liquid cleaning: cleaning of wastewater or removing the solids from recirculation liquid.

4. More technical parameter

Model	Dimension	Angle °	Max feeding size	Amplitude	Frequency (r/ min)	Capacity	Power
BTZS-936	900×3600	-5~0	220 mm	6-10 mm	800	200-220	18.5
BTZS-1248	1200×4800		300 mm		800	250-280	22
BTZS-1548	1500×4800		300 mm		700	320-350	30
BTZS-1560	1500×6000		300 mm		700	320-350	30
BTZS-1660	1600×6000		300 mm		700	280-350	30
BTZS-1848	1800×4800		300 mm		700	250-350	30
