Help Center2.4G Digital Wireless Microphone
Related Products
Specifications
12.4Ghz digital wireless2FCC Test passed
3Allow unlimited wireless microphone in same building
4Pairing
SOYO-WMIC2009,developed by SOYO TECHNOLOGY CO. LTD on the basis of SOYO-WM24G02, a digital wireless transceiver, is a Hi-fi wireless digital tour guide system with very good resistance to various RF interferences. It is characterized by a lot of advantages, such as small in size, highly integrated, high quality sound (with HDCD sound effect, and the highest sampling ratio in the field of all our modules so far), broad input voltage range (2.55Volts),audio output up to 60 mw, input interface compatible microphones and stereo audio input, etc.
The module adopts an international band-- 2.4 G ISM, which is free for the global market.
This product supports fixed ID working mode, both peer-to-peer or to groups, as well as automatic sweep frequency function. It is quite easy and convenient to use. Once ID is paired, the receiver or receivers, placed at random, will receive signals from the RF transmitter automatically. If there is any interference in the current channel, just change the current channel. It features audio muting function in case there should be no or weak signals
There are 80 channels available, the number of which has been the largest in the industry so far. Simultaneous interpretation, Multi-channel player as well as some other applications can also be available by selecting channels manually.
SOYO-WMIC2009 is the best choice for users and Karaok/Singing /Wireless microphone application/Tour Guider/Museums/Scene/Factory users to enjoy high quality wireless audio transmission.
1.1 Performance characteristics
-
- Frequency: 2.4002.483MHz
- Channels: 80
- Small in size and highly integrated
- Fast installation, mobile and flexible
- Lowest latency in the industry (<0.5ms), excerllent surrounding effect.
- Low power consumption for a wide range of input voltage. Transmitters can continuously work at least for 8 hours. Receivers can continuously work at least for 20 hours
- Waist transmitter can be powered by dry batteries or rechargeable batteries as you choose.
- Two types of input supporting microphones and stereo. (Decided when ordering) ( Please refer to the Chapter: Guide for Ordering)
- We have the highest sampling ratios in the industry: 64k@16bit2; frequency response 2020KHz; HDCD sound effect
- Audio muting function when receiving weak signals or no signals. (Note 1)
- Function of auto channel scanning. (Please refer to Guide for Ordering)
- TX power: 1mw-100mw at your option. (Decided when ordering. The default power: 100mw) RF range can be up to 180 meters with the greatest TX power in an open field where there isn't any object between the transmitter and receiver..
- The receiver has the special function of standby dormancy when there is no signal, and the standby current is less than 0.5 mA. (Decided when ordering)
- Flexible design supporting customer functions
- simple to use and fool-operation,
- Capable of being simultaneously used within 200 square meters by at least 20 teams.
