Help CenterMini Blow Film Machine (EN/H-35/40EM)
Related Products
-
EN/H-E Serial High Output Low Power Consume Plastic Film Blown Machine Price,plastic Blow Film MachineUS$ 6,000 - 20,000MOQ: 1 Set -
Single Screw Double Die PE Film Blowing Machine (EN/45C-2D)US$ 20,000 - 23,000MOQ: 1 Set
-
PE Film Blowing Machine In Line Rotogravure Printing Machine (EN-RO)US$ 20,000 - 21,000MOQ: 1 Set
-
PE Film Blowing Machine In Line Flexography Printing MachineUS$ 10,000 - 40,000MOQ: 1 Set
-
EN/45C-2D Double Die Single Screw Plastic Film Extruder MachineUS$ 12,000 - 29,000MOQ: 1 Set
Modle |
EN/H-40EM |
EN/H-45EM |
Suitable material |
HDPE |
HDPE |
Film width |
200-400mm |
200-500mm |
Film thickness |
0.007-0.03mm |
0.007-0.03mm |
Extrusion output |
20-30kg/hr |
25-35kg/hr |
EXTRUDER | ||
Screw diameter |
Φ40 |
Φ45 |
Screw L/D length |
30:1 |
30:1 |
Screw material |
SACM-645/38 CRMOALA |
SACM-645/38 CRMOALA |
Cylinder material |
SACM-645/38 CRMOALA |
SACM-645/38 CRMOALA |
Cylinder cooling blower |
250W×2 SETS |
250W×2 SETS |
Main motor |
7.5 Kw |
11 Kw |
Temperature control |
2 heating zones |
2 heating zones |
Average power-consume |
9Kw |
13Kw |
TYPE OF DIE | ||
Die size |
Φ40/50 |
Φ40/60 |
Temperature control For die |
2 heating zones |
2 heating zones |
Filter |
1 heating zones |
1 heating zones |
Air ring |
1set |
1set |
Air blower |
1.1Kw |
1.5Kw |
TAKE-UP UNIT | ||
Roller width |
Φ165×500mm |
Φ165×600mm |
Effective width |
400mm |
500mm |
Take-up speed |
10-100m/min |
10-100m/min |
Take-up motor |
0.75Kw |
0.75Kw |
WINDING UNIT | ||
Type |
SURFACE FRICTION TYPE |
SURFACE FRICTION TYPE |
Winding motor |
5N.m |
5N.m |
Winding speed |
10-100m/min |
10-100m/min |
Overall dimension(L×W×H) |
3.5×2.6×3.5m |
3.5×2.6×3.5m |
Guarantee period and after-sales services:
12 months since installation finish and machine normal working. During this guarantee period, RUIAN ENOCH will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, RUIAN ENOCH will provide spare parts at cost price.
Long-term service:
RUIAN ENOCH will charge the buyer the cost price of spare parts beyond guarantee time and provide long-term technical guide.
Engineer service:
Installation and Adjusting: If required, the seller will dispatch the technician to your country for installation, commissioning, adjusting the machine and training the workers at your plant. After the Machine arrived destination and the customer wants our technician help them running the machine, we will sent our technician to the place of our customer’s factory and training them, but they should pay the charge as bellowed:1: The charge of the VISA 2:The ticket of the air plane from Our city to the Destination place and the Destination place to our city.3:Hotel 4:Pay the salary to the technician 100 USD per day.
Mini Blown Film Extruders (EN/H-EM) Double Lines Pe Plastic Film Extruder Double Rewinder Film Blowing Machine
Cold Cutting T-shirt Bag Maker Hot Cutting T-shirt Bag Maker Cold Cutting Flat Bag Maker
