WM205 Semi-Auto Pallet Wrapper Mechanical Brake

WM205 Semi-Auto Pallet Wrapper Mechanical Brake photo-1
US$ 1,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Other, Machinery & Hardware
Packaging Type Cartons
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Power 220V AC, 50/60 Hz, 20A, 1.35Kw
Place of Origin Guangdong, China
Brand Name FBI
Model Number WM205

Specifications

1.The best supplier of good quality wrapping machine
2.17 years experience in packing industry
3.Provide customized design



FBI Packing Co., Ltd is specialized in manufacturing with wide
range of stretch wrapping machines. We are the best supplier for
customized design according to the customer's requirement.
WM205 Semi-Auto Pallet Wrapper Mechanical Brake

We adopt PLC control System and touch screen for easy
operating and reliable performance, requiring no maintenance.

Since establishment in 1994, FBI is making great progresses
in the packing industry. We always design the machine as your
special need. Just let me know your real requirement, then we
can figure it out.

Our experience and diverse knowledge of packing machinery
enables us to provide perfect solutions to meet specific packing
need with different industries. Please no hesitate to contact us.
Leave us a message and let us find the solution.

 WM205 Semi-Auto Pallet Wrapper Mechanical Brake

Features



WM205 Semi-auto Pallet Wrapper Mechanical Brake offers the best value for factory operators to increase worker efficiency and reduce labor.
1.Mechanical brake film carriage, ratio 150%.
2.Dual chain structure column, carriage speed vairable.
3.Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles, top/bottom cycles & film tension. Manual wrap mode as an option.
4.Auto height detection, turntable home position, forklift sockets for easy moving.
5.Dual limit switches on top & bottom to provide better safety protections.



Technical Specifications

Overall dimensions 2565mm (L) X 1500mm (W) X 2535mm (H)
Turntable 1500mm(Ø) X 82mm(H),                                               optional 1650mm(Ø) X 82mm(H),1800mm(Ø) X 82mm(H)
Wrapping height 2100mm, optional 2400mm, 2600mm
Machine Weight   680kg
Maximum load weight 2000kg
Throughput 20-40 pallet/hour
Rotation speed  0-15 rpm, speed variable,turntable soft start & soft stop
Film carriage lift speed 3m/min
Controller PLC
Power requirements 1PH220VAC, 50/60Hz, 20A, 1.15kw
