Pallet Wrapping Machine WM101 Pre-Stretch Semi-Auto

Pallet Wrapping Machine WM101 Pre-Stretch Semi-Auto photo-1
US$ 2,500 - 5,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Packaging Material:
Plastic
Automatic Grade:
Semi-Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Power 1.35kw
Place of Origin Guangdong, China
Brand Name FBI
Model Number WM101

Specifications

1.Leading Manufacturer of pallet wrapping machine
2.High Tech Innovative Enterprise
3.Customized Design
4.mainly export to US

Features

Stretch wrapping machines are used to wrap stretch film around a loaded pallet. Film provides extra support during transportation and storage to protect them from dust, moisture or damage. It’s been widely used in industries such as glassware, tools, electric & electronic, paper, pottery, food & beverage, etc.

 Pallet Wrapping machine WM101 Pre-Stretch Semi-Auto

1.Powered pre-stretch film carriage, ratio 250%.
2.Dual chain structure column, carriage speed vairable.
3.Automatic wrapping according to pre-set parameters. Friendly user interface for setting wrap cycles, top/bottom cycles & film tension. Manual wrap mode as an option.
4.Auto height detection, turntable home position, forklift sockets for easy moving.
5.Dual limit switches on top & bottom to provide better safety protections.



Technical Specifications

Overall dimensions 2565mm (L) X 1500mm (W) X 2535mm (H)
Turntable 1500mm(Ø) X 82mm(H),                                  optional 1650mm(Ø) X 82mm(H),1800mm(Ø) X 82mm(H)
Wrapping height 2100mm, optional 2400mm, 2600mm
Machine Weight   700kg
Maximum load weight 2000kg
Throughput 20-40 pallet/hour
Rotation speed  0-15 rpm, speed variable,turntable soft start & soft stop
Film carriage lift speed 3m/min
Controller PLC
Working mode auto/manual
Power requirements 1PH220VAC, 50/60Hz, 20A, 1.35kw



Pallet Wrapping machine WM101 Pre-Stretch Semi-Auto



Pallet Wrapping machine WM101 Pre-Stretch Semi-Auto
